    LVDT

    VL7A 型

    交流-交流长行程位移传感器。导向式弹簧自回位衔铁,±0.5 英寸至 ±3.0 英寸。±0.25% F.S. 非线性

    Overview

    VL7A AC-AC 型长行程位移传感器配备专用导向弹簧回复电枢,范围从 ±0.5 至 ±3.0 in,满量程精度为 ±0.25%。根据行程长度,输出范围从 2.4 V RMS @ 3 V RMS 至 4.8 V RMS,3 V RMS。电源可通过 5 vdc 校准电源或 1 V 至 7 V RMS 可接受电源操作。装置操作温度范围 -58°F 至 +257°F,采用不锈钢结构主体及有多芯屏蔽电缆。

    特征
    • 非线性:0.25%
    • 不锈钢构造
    • 范围:12.7 mm 至 76.2 mm [0.5 英寸至 3.0 英寸]
    • 高级电气噪音抗干扰性
    • 分辨率高
    • 工作温度范围(标配):-58°F 至 257°F
    • 弹簧复位电枢
    • 不符合 RoHS 标准
