CT40 XP HC Enterprise Mobile Computer
CT40 XP HC Enterprise Mobile Computer for Healthcare
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Features
- Housing Grade
- Healthcare
- Application
- Healthcare
- Features
- The Mobility Edge enterprise management tools allow hospitals to test and validate applications once, accelerate deployments, optimize device performance, simplify maintenance
- Camera
- 8MP/13MP
- Camera Position
- 13-megapixel color camera with autofocus, 8-megapixel front facing camera
Dimensions
- Overall Dimensions
- 162 mm x 77 mm x 18.2 mm (6.4 in x 3.0 in x 0.7 in)
Scanning Specifications
- Decode Capability
- Honeywell N6700 Slim Imager 1D/2D barcode symbologies, Honeywell SDKs for Android
Network
- Computer Wireless Communication
- WIFI, BT, 2nd BLE
- Bluetooth Specifications
- BT 4.2 & BLE
- WWAN Specifications
- WWAN: WWAN Radio (ATT/VZW/SPRINT/TMO/NA/EU)NEWLINELTE Advanced SupportNEWLINEUp to 400 Mbps CAT13 LTE downlinkNEWLINEUp to 75 Mbps CAT5 LTE uplinkNEWLINELTE (FDD): Bands 1, 2, 3, 4, 5, 7, 8, 12, 13,NEWLINE17, 19, 20, 25, 26, 28, 29NEWLINELTE (TDD): Bands 38, 39, 40, 41NEWLINEUMTS/HSPA+ (3G): Bands 1, 2, 4, 5, 6, 8, 9, 19NEWLINEGSM/GPRS/EDGE Quad-BandNEWLINE(850/900/1800/1900 MHz)NEWLINE1xRTT/EV-DO: Bands BC0, BC1, BC10 (B26BW)
- WLAN Specifications
- WLAN: IEEE 802.11 a/b/g/n/ac; Wi-Fi certified, 2*2 MIMONEWLINEAdditional WLAN Features: 802.11 d/e/h/i/k/r/u/w
- GPS Specifications
- Simultaneous GNSS Receiver Support for GPS, GLONASS, Galileo, and Beidou
Software & Firmware
- Operating System
- Starts with Android 9.1; upgradable through Android 12 and 13
- Operating System Type
- Android
- Platform
- MobIlity Edge
Memory & Data
- Memory
- 4GB RAM / 32GB Flash
Hardware
- Display Resolution
- High Definition (1920 x 1080)
- Scan Engine Range
- Standard Range
- Scan Engine Model
- N6700
- Scan Engine Type
- 2D Standard Range
- Display Size
- 12.7 cm (5.0 in)
- Processor
- 2.2 GHz Qualcomm® Snapdragon™ 660 octa-core
- Scan Range
- Standard Range
- Keyboard
- Full touch
- Network
- 4G-LTE and WIFI
Electrical
- Battery Capacity
- 4020mah
- Battery Type
- Smart Battery
Environmental
- Storage Temperature Range
- 30°C to +70°C (-22°F to +158°F)
- Operating Temperature
- -20°C to +50°C (-4°F to +122°F)
- Operating Humidity
- 5% to 95% (non-condensing)
- Cold Storage
- N/A
Standards & Approvals
- Incendiary Specifications
- N/A
- Tumble Specifications
- 1,000 times at 0.5 m (1.6 ft)
- Drop Specifications
- Multiple 1.2 m (4 ft) drops to concrete at -10°C to +50°C (+14°F to +122°F).
Service Terms
- Warranty Duration
- 1 year warranty
ERP
- Brand
- Honeywell
Features
- Housing Grade
- Healthcare
- Application
- Healthcare
- Features
- The Mobility Edge enterprise management tools allow hospitals to test and validate applications once, accelerate deployments, optimize device performance, simplify maintenance
- Camera
- 8MP/13MP
- Camera Position
- 13-megapixel color camera with autofocus, 8-megapixel front facing camera
Dimensions
- Overall Dimensions
- 162 mm x 77 mm x 18.2 mm (6.4 in x 3.0 in x 0.7 in)
Scanning Specifications
- Decode Capability
- Honeywell N6700 Slim Imager 1D/2D barcode symbologies, Honeywell SDKs for Android
Network
- Computer Wireless Communication
- WIFI, BT, 2nd BLE
- Bluetooth Specifications
- BT 4.2 & BLE
- WWAN Specifications
- WWAN: WWAN Radio (ATT/VZW/SPRINT/TMO/NA/EU)NEWLINELTE Advanced SupportNEWLINEUp to 400 Mbps CAT13 LTE downlinkNEWLINEUp to 75 Mbps CAT5 LTE uplinkNEWLINELTE (FDD): Bands 1, 2, 3, 4, 5, 7, 8, 12, 13,NEWLINE17, 19, 20, 25, 26, 28, 29NEWLINELTE (TDD): Bands 38, 39, 40, 41NEWLINEUMTS/HSPA+ (3G): Bands 1, 2, 4, 5, 6, 8, 9, 19NEWLINEGSM/GPRS/EDGE Quad-BandNEWLINE(850/900/1800/1900 MHz)NEWLINE1xRTT/EV-DO: Bands BC0, BC1, BC10 (B26BW)
- WLAN Specifications
- WLAN: IEEE 802.11 a/b/g/n/ac; Wi-Fi certified, 2*2 MIMONEWLINEAdditional WLAN Features: 802.11 d/e/h/i/k/r/u/w
- GPS Specifications
- Simultaneous GNSS Receiver Support for GPS, GLONASS, Galileo, and Beidou
Software & Firmware
- Operating System
- Starts with Android 9.1; upgradable through Android 12 and 13
- Operating System Type
- Android
- Platform
- MobIlity Edge
Memory & Data
- Memory
- 4GB RAM / 32GB Flash
Hardware
- Display Resolution
- High Definition (1920 x 1080)
- Scan Engine Range
- Standard Range
- Scan Engine Model
- N6700
- Scan Engine Type
- 2D Standard Range
- Display Size
- 12.7 cm (5.0 in)
- Processor
- 2.2 GHz Qualcomm® Snapdragon™ 660 octa-core
- Scan Range
- Standard Range
- Keyboard
- Full touch
- Network
- 4G-LTE and WIFI
Electrical
- Battery Capacity
- 4020mah
- Battery Type
- Smart Battery
Environmental
- Storage Temperature Range
- 30°C to +70°C (-22°F to +158°F)
- Operating Temperature
- -20°C to +50°C (-4°F to +122°F)
- Operating Humidity
- 5% to 95% (non-condensing)
- Cold Storage
- N/A
Standards & Approvals
- Incendiary Specifications
- N/A
- Tumble Specifications
- 1,000 times at 0.5 m (1.6 ft)
- Drop Specifications
- Multiple 1.2 m (4 ft) drops to concrete at -10°C to +50°C (+14°F to +122°F).
Service Terms
- Warranty Duration
- 1 year warranty
ERP
- Brand
- Honeywell
- Housing Grade : Healthcare
- Application : Healthcare
- Features : The Mobility Edge enterprise management tools allow hospitals to test and validate applications once, accelerate deployments, optimize device performance, simplify maintenance
- Camera : 8MP/13MP
- Overall Dimensions : 162 mm x 77 mm x 18.2 mm (6.4 in x 3.0 in x 0.7 in)
- Decode Capability : Honeywell N6700 Slim Imager 1D/2D barcode symbologies, Honeywell SDKs for Android
- Computer Wireless Communication : WIFI, BT, 2nd BLE
- Bluetooth Specifications : BT 4.2 & BLE
- WWAN Specifications : WWAN: WWAN Radio (ATT/VZW/SPRINT/TMO/NA/EU)NEWLINELTE Advanced SupportNEWLINEUp to 400 Mbps CAT13 LTE downlinkNEWLINEUp to 75 Mbps CAT5 LTE uplinkNEWLINELTE (FDD): Bands 1, 2, 3, 4, 5, 7, 8, 12, 13,NEWLINE17, 19, 20, 25, 26, 28, 29NEWLINELTE (TDD): Bands 38, 39, 40, 41NEWLINEUMTS/HSPA+ (3G): Bands 1, 2, 4, 5, 6, 8, 9, 19NEWLINEGSM/GPRS/EDGE Quad-BandNEWLINE(850/900/1800/1900 MHz)NEWLINE1xRTT/EV-DO: Bands BC0, BC1, BC10 (B26BW)
- WLAN Specifications : WLAN: IEEE 802.11 a/b/g/n/ac; Wi-Fi certified, 2*2 MIMONEWLINEAdditional WLAN Features: 802.11 d/e/h/i/k/r/u/w
- GPS Specifications : Simultaneous GNSS Receiver Support for GPS, GLONASS, Galileo, and Beidou
- Operating System : Starts with Android 9.1; upgradable through Android 12 and 13
- Memory : 4GB RAM / 32GB Flash
- Display Resolution : High Definition (1920 x 1080)
- Scan Engine Range : Standard Range
- Scan Engine Model : N6700
- Scan Engine Type : 2D Standard Range
- Display Size : 12.7 cm (5.0 in)
- Processor : 2.2 GHz Qualcomm® Snapdragon™ 660 octa-core
- Battery Capacity : 4020mah
- Battery Type : Smart Battery
- Storage Temperature Range : 30°C to +70°C (-22°F to +158°F)
- Operating Temperature : -20°C to +50°C (-4°F to +122°F)
- Operating Humidity : 5% to 95% (non-condensing)
- Cold Storage : N/A
- Incendiary Specifications : N/A
- Tumble Specifications : 1,000 times at 0.5 m (1.6 ft)
- Drop Specifications : Multiple 1.2 m (4 ft) drops to concrete at -10°C to +50°C (+14°F to +122°F).
- Warranty Duration : 1 year warranty
- Brand : Honeywell
- Operating System Type : Android
- Camera Position : 13-megapixel color camera with autofocus, 8-megapixel front facing camera
- Scan Range : Standard Range
- Platform : MobIlity Edge
- Keyboard : Full touch
- Network : 4G-LTE and WIFI
