    Load Cells

    Model 3124 Series

    Tension/compression inline load cells. 5,000 lb to 25,000 lb capacities. Low deflection at full load.

    Overview
    SUPPORT Where to buy CONTACT US

    Honeywell carbon steel, tension/compression, in-line load cells offer a small diameter design for mounting into an existing work system with tight spaces or clearances.

    Economical and easy to mount, these load cells allow simultaneous testing of multi-element systems and are commonly used in fluid power transfer systems.

    They may be directly attached to the piston rod of hydraulic cylinder. The side-mounted cable connectors allow cable assemblies to be supported without affecting movement of the cell during tension or compression loading.

    Like what you see, but need a special tweak or a custom design? Contact us to discuss your individual requirements.

    Features
    • 5000 lb to 25000 lb range
    • 0.25 % non-linearity
    • 0.15 % hysteresis
    • Adapts directly to hydraulic cylinder
    • Small diameter allows mounting in restricted areas
    • Low deflection
