ScanPal™ EDA71 Enterprise Tablet
Honeywell’s enterprise-class 7-inch tablet, the ScanPal EDA71, delivers real-time connectivity, fast data capture capabilities and enterpriselevel reliability and protection
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
It's like the Swiss Army Knife® of rugged, enterprise tablet computers. The 7-inch ScanPal™ EDA71 tablet equips retail, DSD, field service, and T&L operations with a flexible solution that fits a wide range of workflows. It provides the processing power modern operations need, real-time connectivity for business-critical applications, and enterprise-level reliability, support, and protection.
Helpful accessories
- The carry case with shoulder strap has a 'grab and go' design that lets you instantly shift from comfortably carrying the tablet to full use of all functions while still in the case.
- The ScanPal EDA71 supports Android O, P, and Q, providing the lifecycle you need. Currently, EDA71 is loaded with Android 8 and 10
- Enhanced network connectivity capabilities, including 802.11 a/b/g/n/ac, 2x2 MIMO WLAN, Bluetooth® 4.2, and NFC.
- A sleek, modern, and contemporary design plus enterprise-grade ruggedness. Built tough to withstand 1.2 m (4 ft) drops to concrete, and 200 0.5 m tumbles.
- New memory options, new scanning options, and a powerful new processor platform coupled with new accessories make the ScanPal EDA71 ideal for a wide range of customer needs.
- A new rotating handstrap makes it easy to scan barcodes while holding the tablet with one hand, and convenient to show the screen to a customer.
- Fast Qualcomm Snapdragon SDM450 8-core processor
- Vivid 7-inch Corning® Gorilla Glass® display
- Robust, up-to-date wireless connectivity
- Your choice of 2 scanners
- New accessories
- Retail line busting
- Merchandising in DSD
- Taking inventory at a convenience store
- Retrieving repair history information in the field
- And more
Helpful accessories
- Rotating handstrap: Enables fast, one-handed scanning using side scan triggers and also makes it easy to show the display to customers.
- Carry case with shoulder strap: Quickly switch from carrying the tablet to using it, without having to remove the device from the case. Reduces arm fatigue and frees both hands for other activities.
- eHomeBase: A recharging station with Ethernet and USB ports.
- Vehicle dock: Extend the tablet's capabilities from a vehicle or push cart by connecting a USB peripheral.
Specifications
Features
- Camera Position
- Rear only
- Connectivity
- Wi-Fi
- Environment
- Standard
- Application
- Logistics
- Retail
- Durability
- Durable 1.2 m (4 ft) rm
- Features
- 13 MP Color Camera
- 7-Inch Gorilla Glass Touchscreen Display
- Built for Rugged Environments
- Fast 1D/2D Barcode Scanning
- Flexible Network Coverage
- Industry-Leading Investment Protection
- Powerful, Efficient 8-Core Processor
- Camera
- Yes
Dimensions
- Overall Dimensions
- 21.4 x 11.8 x 2.1 cm
- 8.4 x 4.6 x 0.83 in
Scanning Specifications
- Decode Capability
- 1D
- 2D
Network
- Bluetooth Specifications
- V4.2
Software & Firmware
- Operating System Type
- Android
- Operating System
- Android 8
- Platform
- ScanPal
Memory & Data
- Memory
- 32 GB Flash/2 GB RAM
- 64 GB Flash/4 GB RAM
Hardware
- Connection Interface
- Audio
- Ethernet
- USB
- Display Resolution
- 1280 x 720
- Scan Distance
- Standard Range (0-1m)
- Display Size
- 7 in
- Scan Range
- Standard Range
- Processor
- 1.8 GHz Qualcomm® SDM450 octa-core
- Keyboard
- Touchscreen only
- Network
- WLAN
- WLAN/WWAN
- Keypad
- Full Touchscreen
Environmental
- Minimum Operating Temperature
- -10 °C
- 14 °F
- Storage Temperature Range
- - 20 - 70 °C
- - 4 - 158 °F
- Operating Temperature
- - 10 - 50 °C
- 14 - 122 °F
- Operating Humidity
- 10 - 90 %
Standards & Approvals
- Tumble Specifications
- Exceeds 200 times at 0.5 m (1.64 ft) per IEC 60068-2-32 specification
- Drop Specifications
- 1.2 m (4 ft) to concrete at room temp (10 °C to 50 °C)
- Protection Ratings
- IP64
Service Terms
- Warranty Duration
- 1 yr
ERP
- Brand
- Honeywell
Others
- Industry
- Logistics & Warehouses
- Manufacturing
Features
- Camera Position
- Rear only
- Connectivity
- Wi-Fi
- Environment
- Standard
- Application
- Logistics
- Retail
- Durability
- Durable 1.2 m (4 ft) rm
- Features
- 13 MP Color Camera
- 7-Inch Gorilla Glass Touchscreen Display
- Built for Rugged Environments
- Fast 1D/2D Barcode Scanning
- Flexible Network Coverage
- Industry-Leading Investment Protection
- Powerful, Efficient 8-Core Processor
- Camera
- Yes
Dimensions
- Overall Dimensions
- 21.4 x 11.8 x 2.1 cm
- 8.4 x 4.6 x 0.83 in
Scanning Specifications
- Decode Capability
- 1D
- 2D
Network
- Bluetooth Specifications
- V4.2
Software & Firmware
- Operating System Type
- Android
- Operating System
- Android 8
- Platform
- ScanPal
Memory & Data
- Memory
- 32 GB Flash/2 GB RAM
- 64 GB Flash/4 GB RAM
Hardware
- Connection Interface
- Audio
- Ethernet
- USB
- Display Resolution
- 1280 x 720
- Scan Distance
- Standard Range (0-1m)
- Display Size
- 7 in
- Scan Range
- Standard Range
- Processor
- 1.8 GHz Qualcomm® SDM450 octa-core
- Keyboard
- Touchscreen only
- Network
- WLAN
- WLAN/WWAN
- Keypad
- Full Touchscreen
Environmental
- Minimum Operating Temperature
- -10 °C
- 14 °F
- Storage Temperature Range
- - 20 - 70 °C
- - 4 - 158 °F
- Operating Temperature
- - 10 - 50 °C
- 14 - 122 °F
- Operating Humidity
- 10 - 90 %
Standards & Approvals
- Tumble Specifications
- Exceeds 200 times at 0.5 m (1.64 ft) per IEC 60068-2-32 specification
- Drop Specifications
- 1.2 m (4 ft) to concrete at room temp (10 °C to 50 °C)
- Protection Ratings
- IP64
Service Terms
- Warranty Duration
- 1 yr
ERP
- Brand
- Honeywell
Others
- Industry
- Logistics & Warehouses
- Manufacturing
- Camera Position : Rear only
- Connectivity : Wi-Fi
- Environment : Standard
- Application : Logistics|Retail
- Durability : Durable 1.2 m (4 ft) rm
- Features : 13 MP Color Camera|7-Inch Gorilla Glass Touchscreen Display|Built for Rugged Environments|Fast 1D/2D Barcode Scanning|Flexible Network Coverage|Industry-Leading Investment Protection|Powerful, Efficient 8-Core Processor
- Camera : Yes
- Overall Dimensions : 21.4 x 11.8 x 2.1 cm|8.4 x 4.6 x 0.83 in
- Decode Capability : 1D|2D
- Bluetooth Specifications : V4.2
- Operating System Type : Android
- Operating System : Android 8
- Platform : ScanPal
- Memory : 32 GB Flash/2 GB RAM|64 GB Flash/4 GB RAM
- Connection Interface : Audio|Ethernet|USB
- Display Resolution : 1280 x 720
- Scan Distance : Standard Range (0-1m)
- Display Size : 7 in
- Scan Range : Standard Range
- Processor : 1.8 GHz Qualcomm® SDM450 octa-core
- Keyboard : Touchscreen only
- Network : WLAN|WLAN/WWAN
- Keypad : Full Touchscreen
- Minimum Operating Temperature : -10 °C|14 °F
- Storage Temperature Range : - 20 - 70 °C|- 4 - 158 °F
- Operating Temperature : - 10 - 50 °C|14 - 122 °F
- Operating Humidity : 10 - 90 %
- Tumble Specifications : Exceeds 200 times at 0.5 m (1.64 ft) per IEC 60068-2-32 specification
- Drop Specifications : 1.2 m (4 ft) to concrete at room temp (10 °C to 50 °C)
- Protection Ratings : IP64
- Warranty Duration : 1 yr
- Brand : Honeywell
- Industry : Logistics & Warehouses|Manufacturing
