    Handheld Computers

    EDA61K Handheld Computer

    EDA61K Handheld Computer

    Overview
    The Honeywell ScanPal™ EDA61K is a rugged, keyed mobile computer that helps businesses automate and error-proof workflows in indoor or outdoor warehouses, distribution centers and retail backrooms. With a battery that lasts for two to three shifts and a lightweight, ergonomically balanced design that minimizes user fatigue, the EDA61K helps keep material flowing smoothly all day long, even during peak season.
    • Responsive performance and quick access to businesscritical information with the speedy Qualcomm 1.8 GHz octa-core chipset, ample memory and reliable Wi-Fi.
    • Snappy, accurate data capture from a few centimeters to up to 15 meters (49.2 feet)with Honeywell’s slim N6703 and long-range EX20 scan imagers, and a 13-megapixel, autofocus camera.
    • Uninterrupted operation for more than two full shifts with Honeywell’s 7,000 mAh, hotswappable, lithium-ion smart battery pack that lasts 25 hours on a single charge.
    • Stay connected with fast, dual-band, 802.11 a/b/ g/n/ac Wi-Fi, Bluetooth® 4.2 and cellular support in most countries.
    Available with both 34-key numeric and 47-key alpha-numeric keypad options, and a choice of scan engines that read from a few centimeters to up to 15 meters, the EDA61K is available in configurations suitable for most applications. The EDA61K comes with 4G LTE cellular support in many countries, making it possible to eliminate Wi-Fi infrastructure in some cases. Combined with a rugged package that survives repeated 1.5-meter (4.9 ft) drops to concrete, this means you can be confident that the EDA61K will deliver reliable, secure, compatible performance for years, maximizing return on investment. In addition to traditional keypads, the EDA61K is available with pre-licensed StayLinked SmartTE software and a sensitive, 4-inch touchscreen that make it suitable for younger workforces more accustomed to touchscreens, reducing training and adoption time – a key advantage for enterprises employing temporary workers during peak seasons.
    Specifications

    Features

    • Camera
      • 13.0-megapixel color camera with autofocus and LED flash

    Dimensions

    • Overall Dimensions
      • 206 mm x 78 mm x 41.9 mm
      • 8.1 in x 3.1 in x 1.6 in

    Network

    • GPS Specifications
      • Integrated GPS
    • Bluetooth Specifications
      • Class 4.2

    Software & Firmware

    • Operating System
      • Android 9, upgradable to Android 10

    Memory & Data

    • Memory
      • 3 GB RAM, 32 GB Flash

    Hardware

    • Display Size
      • 4 in
    • Processor
      • Qualcomm SDM450 1.8 GHz octacore

    Electrical

    • Battery Type
      • Li-Ion, 3.6V, 7,000 mAh

    Environmental

    • Operating Humidity
      • 10% - 90% (non-condensing)
    • Operating temperature
      • -20°C - 50°C
      • -4°F - 122°F
    • Storage Temperature Range
      • -22°F - 158°F
      • -30°C - 70°C

    Standards & Approvals

    • Drop Specifications
      • Multiple 1.5 m (5 ft) drops to concrete at room temperature
    • Protection Ratings
      • IP65
    • Tumble Specifications
      • 1,000 tumbles at 1 m (3.3 ft)

    Service Terms

    • Warranty Duration
      • One-year factory warranty

    ERP

    • Brand
      • Honeywell

    Others

    • Camera Position
      • Rear only
    • Durability
      • Rugged 1.5 m (5 ft)
    • Keyboard
      • Alphanumeric
      • Numeric
    • Scan Range
      • Long Range
      • Standard Range
    • Platform
      • ScanPal
    • Network
      • WLAN
      • WLAN/WWAN
    • Operating System Type
      • Android

    Features

    • Camera
      • 13.0-megapixel color camera with autofocus and LED flash

    Dimensions

    • Overall Dimensions
      • 206 mm x 78 mm x 41.9 mm
      • 8.1 in x 3.1 in x 1.6 in

    Network

    • GPS Specifications
      • Integrated GPS
    • Bluetooth Specifications
      • Class 4.2

    Software & Firmware

    • Operating System
      • Android 9, upgradable to Android 10

    Memory & Data

    • Memory
      • 3 GB RAM, 32 GB Flash

    Hardware

    • Display Size
      • 4 in
    • Processor
      • Qualcomm SDM450 1.8 GHz octacore

    Electrical

    • Battery Type
      • Li-Ion, 3.6V, 7,000 mAh

    Environmental

    • Operating Humidity
      • 10% - 90% (non-condensing)
    • Operating temperature
      • -20°C - 50°C
      • -4°F - 122°F
    • Storage Temperature Range
      • -22°F - 158°F
      • -30°C - 70°C

    Standards & Approvals

    • Drop Specifications
      • Multiple 1.5 m (5 ft) drops to concrete at room temperature
    • Protection Ratings
      • IP65
    • Tumble Specifications
      • 1,000 tumbles at 1 m (3.3 ft)

    Service Terms

    • Warranty Duration
      • One-year factory warranty

    ERP

    • Brand
      • Honeywell

    Others

    • Camera Position
      • Rear only
    • Durability
      • Rugged 1.5 m (5 ft)
    • Keyboard
      • Alphanumeric
      • Numeric
    • Scan Range
      • Long Range
      • Standard Range
    • Platform
      • ScanPal
    • Network
      • WLAN
      • WLAN/WWAN
    • Operating System Type
      • Android
    • Camera : 13.0-megapixel color camera with autofocus and LED flash
    • Overall Dimensions : 206 mm x 78 mm x 41.9 mm|8.1 in x 3.1 in x 1.6 in
    • GPS Specifications : Integrated GPS
    • Bluetooth Specifications : Class 4.2
    • Operating System : Android 9, upgradable to Android 10
    • Memory : 3 GB RAM, 32 GB Flash
    • Display Size : 4 in
    • Processor : Qualcomm SDM450 1.8 GHz octacore
    • Battery Type : Li-Ion, 3.6V, 7,000 mAh
    • Operating Humidity : 10% - 90% (non-condensing)
    • Operating temperature : -20°C - 50°C|-4°F - 122°F
    • Storage Temperature Range : -22°F - 158°F|-30°C - 70°C
    • Drop Specifications : Multiple 1.5 m (5 ft) drops to concrete at room temperature
    • Protection Ratings : IP65
    • Tumble Specifications : 1,000 tumbles at 1 m (3.3 ft)
    • Warranty Duration : One-year factory warranty
    • Brand : Honeywell
    • Camera Position : Rear only
    • Durability : Rugged 1.5 m (5 ft)
    • Keyboard : Alphanumeric|Numeric
    • Scan Range : Long Range|Standard Range
    • Platform : ScanPal
    • Network : WLAN|WLAN/WWAN
    • Operating System Type : Android
