압력 센서
기본 NBP 시리즈
비보정. 저압 절대, 게이지. mV 출력. DIP, 무연 SMT, SMT. 정확도: ±0.25 %FSS BFSL. 비용 효율적
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
제품설명
압력 범위:
- TBP 시리즈: 60 mbar ~ 10 bar | 6 kPa ~ 1 MPa | 1 psi ~ 150 psi, 밀리볼트 아날로그 출력
- NBP 시리즈: 60 mbar ~ 10 bar | 1 psi ~ 150 psi, 밀리볼트 아날로그 출력
설명
Honeywell의 기본 보드 장착 압력 센서 TBP 시리즈 및 NBP 시리즈는 앞으로 식품 등급 및 비식품 등급을 의료 및 산업에 적용할 수 있도록 설계되었습니다. 비증폭 압전저항형 실리콘 압력 센서는 비율계량적 출력을 제공하며, 온도 보정형(TBP 시리즈) 또는 비보정형(NBP 시리즈)입니다.
TBP 시리즈
- 온도 보정 및 비증폭
- 보정은 온도에 따라 시스템을 정기적으로 보정할 필요성을 최소화하므로 센서를 시스템에 통합하기 쉽고, 부품 간 격차도 감소됩니다.
- 압력 신호의 무한 분해능 제공
- 0°C~85°C[-32°F~185°F]의 보정 온도 범위
NBP 시리즈
- 비보정 및 비증폭
- 베어 센서 출력에서 최대 분해능을 생성하기 위해 자체적으로 보정, 교정 및 증폭을 원하는 고객에게 주로 이상적이고, 해당 분야에 필요한 모든 알고리즘을 활용할 수 있습니다.
- 압력 신호의 무한 분해능 제공
이 제품은 다양한 패키지 스타일과 장착 옵션으로 이용 가능하기 때문에 장치 제조업체들이 이 제품을 자사의 응용 분야에 쉽게 통합할 수 있습니다. 공기 및 기타 건식 가스 등의 비부식성, 비이온 가스용이고, 실리콘 겔 코팅 옵션을 선택한 경우 비부식성 비이온 액체용으로 이용 가능합니다. 모든 제품은 ISO 9001에 따라 설계, 제조되었으며 NSF 인증을 받았습니다.
고객에게 제공되는 가치
- 비용 경쟁력 있는 압력 감지 솔루션
- 많은 유사 제품과 비교할 때 인쇄 회로판(PCB)의 공간을 적게 차지하며 일반적으로 PCB 또는 소형 장치에 더 쉽게 배치할 수 있습니다.
- 건식 및 습식 매체가 있는 여러 거친 환경에서 작동
- 다양한 옵션으로 장치 제조업체의 응용 분야에 쉽게 통합할 수 있습니다.
- 북미, 유럽 및 아시아의 식품 안전 인증
