    힘 센서

    FSS 시리즈

    0N ~ 20N 힘 범위. 비증폭, 비보상. 360mV 일반 출력. 낮은 편향. 소형 크기

    제품설명

    FSS 시리즈 힘 센서는 비용 효율적인 가격으로 소형 상업용 등급 패키지로 정밀하고 신뢰할 수 있는 힘 센싱 성능을 제공합니다. 이 센서는 특수 압전저항체 미세 가공 실리콘 감지 소자를 이용하는 입증된 감지 기술을 특징으로 합니다. 저전력 비증폭 비보정 Wheatstone 브리지 회로 설계로 힘 범위 내에서 본질적으로 안정적인 mV 출력을 생성합니다.

    힘 센서는 힘이 가해졌을 때 저항기가 수축하면 실리콘이 삽입된 압전저항체의 저항이 증가한다는 원리로 작동합니다. 이 센서는 응용 분야 내에서 얻은 힘을 스테인리스강 볼을 통해서 실리콘 감지 소자로 직접적으로 집중시킵니다. 저항의 양은 적용되는 힘의 양에 비례하여 변경됩니다. 이 회로 저항의 변경으로 인해 해당 mV 출력 레벨이 변경됩니다.

    센서 패키지 설계는 특허받은 모듈식 구조를 채택하고 있습니다. 혁신적인 탄성중합 기술과 공학적으로 주조된 플라스틱을 사용하여 정격 하중에 비해 최대 세 배의 오버포스 용량을 얻을 수 있습니다. 스테인리스강 볼을 이용해 우수한 기계적 안정성을 제공하고 다양한 분야에 적용 가능합니다.

    FSS 시리즈 센서는 50°C[122°F]에서실시한 평균 고장 수명(MCTF) 신뢰도 테스트에서 2천만 작동 횟수를 달성했습니다. 이 테스트는 풀 스케일에서 고장 없이 센서의 작동 가능 횟수를 판별합니다.

    데이터시트
    Name
    Description
    File Size
    Date
    Size
    FSS Series Low Profile Force Sensors
    application/pdf 345.25 KB
    9/14/2021
    345.25 KB
    매뉴얼 및 가이드
    Name
    Description
    File Size
    Date
    Size
    Sensor Evaluation Board (SEB) User Instructions
    application/pdf 1.53 MB
    7/25/2024
    1.53 MB
    Airflow, Force and Pressure Sensor Product Range Guide
    application/pdf 4.24 MB
    7/25/2024
    4.24 MB
    설치 안내
    Name
    Description
    File Size
    Date
    Size
    FSS Series Low Profile Force Sensors
    application/pdf 379.93 KB
    9/14/2021
    379.93 KB
    브로슈어
    Name
    Description
    File Size
    Date
    Size
    Sensors and Switches for Medical Applications
    application/pdf 10.13 MB
    9/14/2021
    10.13 MB
    Embedded Products in Hospital Applications
    application/pdf 4.7 MB
    6/12/2023
    4.7 MB
    어플리케이션 노트
    Name
    Description
    File Size
    Date
    Size
    Defence Ground Vehicles -
    application/pdf 872.87 KB
    6/14/2023
    872.87 KB
    Solutions for Infusion Pumps
    application/pdf 2.35 MB
    6/12/2023
    2.35 MB
    Sensors and Switches: Solutions for Medical Applications
    application/pdf 1.31 MB
    5/18/2023
    1.31 MB
    제품 사진
    Name
    Description
    File Size
    Date
    Size
    FSS Series Product Photo
    application/zip 66.05 KB
    9/14/2021
    66.05 KB
    FSS Series highres photo.jpg
    image/jpeg 52.3 KB
    9/14/2021
    52.3 KB
    FSS Series lowres photo.jpg
    image/jpeg 19.93 KB
    9/14/2021
    19.93 KB
    Name
    Description
    File Size
    Date
    Size
    FSS Series Low Profile Force Sensors
    application/pdf 379.93 KB
    9/14/2021
    379.93 KB
    Sensor Evaluation Board (SEB) User Instructions
    application/pdf 1.53 MB
    7/25/2024
    1.53 MB
    Airflow, Force and Pressure Sensor Product Range Guide
    application/pdf 4.24 MB
    7/25/2024
    4.24 MB
    Defence Ground Vehicles -
    application/pdf 872.87 KB
    6/14/2023
    872.87 KB
    Sensors and Switches for Medical Applications
    application/pdf 10.13 MB
    9/14/2021
    10.13 MB
    Embedded Products in Hospital Applications
    application/pdf 4.7 MB
    6/12/2023
    4.7 MB
    FSS Series Product Photo
    application/zip 66.05 KB
    9/14/2021
    66.05 KB
    FSS Series highres photo.jpg
    image/jpeg 52.3 KB
    9/14/2021
    52.3 KB
    FSS Series lowres photo.jpg
    image/jpeg 19.93 KB
    9/14/2021
    19.93 KB
    Solutions for Infusion Pumps
    application/pdf 2.35 MB
    6/12/2023
    2.35 MB
    FSS Series Low Profile Force Sensors
    application/pdf 345.25 KB
    9/14/2021
    345.25 KB
    Sensors and Switches: Solutions for Medical Applications
    application/pdf 1.31 MB
    5/18/2023
    1.31 MB
    Name
    Description
    File Size
    Date
    Size
    FSS Series Low Profile Force Sensors
    345.25 KB
    9/14/2021
    Sensor Evaluation Board (SEB) User Instructions
    1.53 MB
    7/25/2024
    Airflow, Force and Pressure Sensor Product Range Guide
    4.24 MB
    7/25/2024
    FSS Series Low Profile Force Sensors
    379.93 KB
    9/14/2021
    Sensors and Switches for Medical Applications
    10.13 MB
    9/14/2021
    Embedded Products in Hospital Applications
    4.7 MB
    6/12/2023
    Defence Ground Vehicles -
    872.87 KB
    6/14/2023
    Solutions for Infusion Pumps
    2.35 MB
    6/12/2023
    Sensors and Switches: Solutions for Medical Applications
    1.31 MB
    5/18/2023
    FSS Series Product Photo
    66.05 KB
    9/14/2021
    FSS Series highres photo.jpg
    52.3 KB
    9/14/2021
    FSS Series lowres photo.jpg
    19.93 KB
    9/14/2021
    Product Number
    Part Number
    Description
    Leaf Category
    Thumbnail
    Add to list
    FSS020WNSB
    FSS Series force sensor, uncompensatedunamplified, low profile SMT package, 0 N to 20 N force range, short tube packaging
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS020WNSB
    FSS Series force sensor, uncompensatedunamplified, low profile SMT package, 0 N to 20 N force range, short tube packaging
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NGR
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NGR
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NGT
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NGT
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NSB
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NSB
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NSR
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NSR
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NST
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
    FSS1500NST
    https://s7d1.scene7.com/is/image/Honeywell65/sps-siot-fss-series-1658-ciid-161041
