    Limit Switches

    HDLS Fully Potted Series

    Rugged metal, epoxy sealed housing. Non-plug in. NEMA 1, 3, 4, 6, 6P, 12, 13 sealing. 30 mm x 60 mm mounting centers. UL/CSA approvals

    Overview
    SUPPORT Where to buy CONTACT US

    Distributor Inventory

    Fully potted MICRO SWITCH HDLS heavy-duty limit switches provide an extra degree of protection in harsh environments by sealing the basic switch cavity with epoxy. These switches are the same as the non- plug-in HDLS except that the entire switch cavity is filled with epoxy in addition to the conduit entrance. The fully potted HDLS switches are pre-leaded, with either cable or connectors.

    • Excellent sealing capability for harsh-duty food and beverage wash downs and severe machine tool environments
    • Diaphragm sealing
    • 12 inch STOOW-A cable (other lengths available) or connector version
    • Cable versions: NEMA 1, 6, 6P, 12
    • Connector versions: NEMA 1, 6, 6P, 12, 13
    • All fluorocarbon seals (low temperature fluorosilicone seals available)
    • UL, CSA, CE, CCC
    Data Sheet
    Name
    Description
    File Size
    Date
    Size
    MICRO SWITCH HDLS Heavy-Duty Factory Sealed Limit Switches (LSY-FP Series)
    MICRO SWITCH HDLS Heavy-Duty Factory Sealed Limit Switches (LSY-FP Series)
    application/pdf 9.76 MB
    11/17/2022
    9.76 MB
