    Basic Switches

    ZM Series

    Up to 10.1 A ac & 0.1 A dc (UL, cUL, CQC). Variety of actuators, forces, terminations, contacts. 9,5 mm centers side mount.

    Overview
    SUPPORT Where to buy CONTACT US

    Distributor Inventory

    Although small in size, the ZM and ZM1 Series are rated for controlling electrical loads ranging from logic level (computer based circuits) to power duty switching (up to 16.1 A and 250 Vac). The package size of the subminiature switch is ideal for applications where space on the equipment is at a premium. The overall length of the ZM and ZM1 Series are less than 20 mm [0.78 in].
