Systevo Legacy
Auto-release plug system - L-coded
Auto-release plug L-coded for the connection of handheld switches and multiple buttons with self-release plug, matches flush-mounted combination sockets and flush-mounted outlet sockets with screw-fastening track 60 mm.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
This product is no longer available
Part Number: 74189L
Auto-release plug L-coded for the connection of handheld switches and multiple buttons with self-release plug, matches flush-mounted combination sockets and flush-mounted outlet sockets with screw-fastening track 60 mm. This design must be used in systems, if bed modules BM99 are installed in other rooms.
Accessories
88910N3N - Cover plate for auto-release plug system.
Specifications
Technical Specifications
- Mounting
- Flush (DIN 49073)
Standards & Certifications
- Type Of Protection
- IP40 (When Installed Inclusive Suitable Cover Plate)
Dimensions & Weight
- Dimensions
- W: 71 mm H: 71 mm
Technical Specifications
- Mounting
- Flush (DIN 49073)
Standards & Certifications
- Type Of Protection
- IP40 (When Installed Inclusive Suitable Cover Plate)
Dimensions & Weight
- Dimensions
- W: 71 mm H: 71 mm
- Mounting : Flush (DIN 49073)
- Type Of Protection : IP40 (When Installed Inclusive Suitable Cover Plate)
- Dimensions : W: 71 mm H: 71 mm
