    로드셀

    모델 3124 시리즈

    장력/압축 인라인 로드셀. 용량 5,000lb ~ 25,000lb. 완전 부하에서 저굴절

    제품설명

    Honeywell 탄소강, 당김/압축, 인라인 로드셀은 좁은 공간이나 간격의 기존 작업 시스템에 탑재하기 위한 소형 외경 설계를 제공합니다.

    경제적이고 장착이 쉬운 이 로드셀은 다중 소자 시스템의 동시 테스팅을 지원하며 일반적으로 유체 동력 전달 시스템에 사용됩니다.

    이 제품은 유압 실린더의 피스톤 막대에 직접 부착할 수 있습니다. 측면 장착 케이블 커넥터는 인장 및 압축 로드에서 셀의 동작에 영향을 미치지 않는 선에서 지원되는 케이블 어셈블리를 허락합니다.

    보시는 것과 흡사하지만 특별한 수정이나 맞춤 설계가 필요합니다. 모델 3124 시리즈 개별 요구사항에 대해 논의하려면 당사에 문의하십시오.

    기능
    • 범위 5000lb ~ 25000lb
    • 0.25% 비선형성
    • 자기이력 0.15%
    • 유압식 실린더에 직접 부착
    • 작은 직경은 제한적 지역의 장착 지원
    • 낮은 굴절

    저희에게 연락하셔서 개별 요구조건에 대해 상담하십시오.
