    ロードセル

    モデル 3124シリーズ

    引張/圧縮インラインロードセル、容量 5,000~25,000lb  フル荷重で低たわみ

    製品概要

    ハネウェルのカーボンスチール、張力/圧縮、インラインロードセルは、狭い場所や障害物のある既存の作業システムに取付けるための小径設計を提供します。

    経済的で取付けが簡単なこれらのロードセルは、複数素子システムの同時試験を可能にし、一般的に、流体動力伝達システムで使用されています。

    油圧シリンダーのピストンロッドに直接取付けることが可能です。サイド取付け用のケーブルコネクタにより、張力または圧縮荷重がかかる間、セルの移動に影響を与えることなく、ケーブルアセンブリを支持します。

    モデル3124のシリーズに特別な調整やカスタム設計が必要とされる場合は、当社までお問い合わせの上、個々の要件についてご相談ください。

    機能
    • 範囲:5000lb~25000lbの範囲
    • 0.25%の非直線性
    • 0.15%のヒステリシス
    • 油圧シリンダーに直接搭載
    • 小径により、限られたスペースに取付け可能
    • 低いたわみ
    ハネウェルまでご連絡ください。個々の要件を検討させていただきます。

    機能
    • 範囲:5000lb~25000lbの範囲
    • 0.25%の非直線性
    • 0.15%のヒステリシス
    • 油圧シリンダーに直接搭載
    • 小径により、限られたスペースに取付け可能
    • 低いたわみ
