    limit switches

    SZL-VL-S Series

    Miniature housing. Direct opening contacts (side rotary only). IP67 sealing. 21 mm x 56 mm mounting centers. CCC/CE/cULus approvals

    Overview
    SUPPORT Where to buy CONTACT US

    Distributor Inventory

    The SZL-VL-S Series miniature-type limit switch is designed for use in applications where limited mounting space is available. With IP67 seal rating, these switches are suitable for OEM machinery that requires a rugged and reliable limit switch capable of being mounted in space restricted applications. Its design enhances ease of wiring with ample wiring space, and has an optional cable gland for faster and more efficient wiring termination.

    The SZL-VL-S Series switches have a split-housing design made of a die-cast body and head with glass-filled, flame-retardant thermoplastic cover. The cover is removable for easy access and ease of installation. Modular actuator head design allows for configurations to meet a variety of application needs. The SZL-VL-S are available globally and carry certifications for applications around the world.

    Specifications

    Others

    • Industry
      • Logistics & Warehouses
      • Manufacturing
      • Utilities

    Others

    • Industry
      • Logistics & Warehouses
      • Manufacturing
      • Utilities
    • Industry : Logistics & Warehouses|Manufacturing|Utilities
    Data Sheet
    Name
    Description
    File Size
    Date
    Size
    MICRO SWITCH SZL-VL-S Miniature Industrial Limit Switch
    MICRO SWITCH SZL-VL-S Miniature Industrial Limit Switch
    application/pdf 1.29 MB
    3/2/2022
    1.29 MB
