    Photoionization Detectors (PID)

    MiniRAE Lite +

    Handheld VOC monitor

    Overview

    This affordable hand-held monitor for VOCs provides superior reliability for leak detection and environmental cleanup and remediation. With a photoionization detector that measures from 0-5,000 ppm, a built-in flashlight, and a rugged housing designed for harsh environments, it’s perfect for a range of applications and approved for safe area use in North America. The pump draws samples from up to 100 feet away, and with a 3-second response time, the MiniRAE Lite + can detect a leak before it can cause harm. This device supports more than 10 languages, and includes a large display and large keys that can be operated with up to three layers of gloves.

    MiniRAE Lite+ can also be solution oriented through its optional BLE module and dedicated mobile APP has been developed for survey applications.

    Features and Benefits:

    • Portable handheld VOC monitor
    • PID measures from 0-5,000 ppm
    • 3-second response time
    • Humidity compensation
    • Built-in flashlight
    • Rugged housing for harsh environments
    • Simple maintenance
    • Multi-language capability – up to 10 languages
    • 10.6 lamps for TVOC
    • Logs up to 6 months of data at 1-minute intervals
    • Optional BLE moduel

    Application:

    • Environmental Cleanups/ Remediation
    • Leak Detection
    Even the best products deserve expert maintenance!

    Elevate your gas detectors’ potential with Honeywell's expert maintenance services! Maximize uptime, eliminate costs, and ensure on-time, on-budget project completion.

    Explore our fixed, portable, and high-tech support services now!

    Specifications

    Brand

    • Brand
      • RAE

    Category

    • Sub-Category
      • Premium-Gas

    Dimension & Weight

    • Instrument Size
      • 10" L x 3.0" W x 2.5" H (25.5 x 7.6 x 6.4 cm)

    Range

    • Humidity Range
      • 0%-95% percent
    • Sensor Range
      • VOC (0-5000ppm)

    Alarm

    • Alarm Type
      • Audible, Visual, Vibrating

    Battery & Charging

    • Battery Run Time
      • 12 hours

    Certifications

    • Standards & Certifications
      • ATEX II 2G EEx ia IIC T4

    Datalogging

    • Datalogging
      • Standard 6 months at one-minute intervals

    Features & Benefits

    • Features & Benefits
      • Proven PID technology

    Options

    • User Options
      • Alarms latching with manual override or automatic reset

    Sampling

    • Sampling Pump Range
      • 100ft (30m) meter

    Warranty

    • Warranty
      • 3 years for 10.6 eV lamp, 1 year for pump, battery and instrument

    Wireless

    • Wireless Technology
      • BLE

    Additional Specifications

    • Ingress Protection
      • IP65
    • Gas Type
      • VOC

    Others

    • Weight
      • 26 ounce av
      • 738 gram
    • Minimum Temperature
      • -20 degree Celsius
      • -4 degree Fahrenheit
    • Maximum Temperature
      • 113 degree Fahrenheit
      • 50 degree Celsius

    Brand

    • Brand
      • RAE

    Category

    • Sub-Category
      • Premium-Gas

    Dimension & Weight

    • Instrument Size
      • 10" L x 3.0" W x 2.5" H (25.5 x 7.6 x 6.4 cm)

    Range

    • Humidity Range
      • 0%-95% percent
    • Sensor Range
      • VOC (0-5000ppm)

    Alarm

    • Alarm Type
      • Audible, Visual, Vibrating

    Battery & Charging

    • Battery Run Time
      • 12 hours

    Certifications

    • Standards & Certifications
      • ATEX II 2G EEx ia IIC T4

    Datalogging

    • Datalogging
      • Standard 6 months at one-minute intervals

    Features & Benefits

    • Features & Benefits
      • Proven PID technology

    Options

    • User Options
      • Alarms latching with manual override or automatic reset

    Sampling

    • Sampling Pump Range
      • 100ft (30m) meter

    Warranty

    • Warranty
      • 3 years for 10.6 eV lamp, 1 year for pump, battery and instrument

    Wireless

    • Wireless Technology
      • BLE

    Additional Specifications

    • Ingress Protection
      • IP65
    • Gas Type
      • VOC

    Others

    • Weight
      • 26 ounce av
      • 738 gram
    • Minimum Temperature
      • -20 degree Celsius
      • -4 degree Fahrenheit
    • Maximum Temperature
      • 113 degree Fahrenheit
      • 50 degree Celsius
    • Brand : RAE
    • Weight : 26 ounce av|738 gram
    • Minimum Temperature : -20 degree Celsius|-4 degree Fahrenheit
    • Maximum Temperature : 113 degree Fahrenheit|50 degree Celsius
    • Sub-Category : Premium-Gas
    • Instrument Size : 10" L x 3.0" W x 2.5" H (25.5 x 7.6 x 6.4 cm)
    • Humidity Range : 0%-95% percent
    • Sensor Range : VOC (0-5000ppm)
    • Alarm Type : Audible, Visual, Vibrating
    • Battery Run Time : 12 hours
    • Standards & Certifications : ATEX II 2G EEx ia IIC T4
    • Datalogging : Standard 6 months at one-minute intervals
    • Features & Benefits : Proven PID technology
    • User Options : Alarms latching with manual override or automatic reset
    • Sampling Pump Range : 100ft (30m) meter
    • Warranty : 3 years for 10.6 eV lamp, 1 year for pump, battery and instrument
    • Wireless Technology : BLE
    • Ingress Protection : IP65
    • Gas Type : VOC
