Vertex™ M Toxic Gas Monitoring System
Multipoint Vertex™ M Toxic Gas Monitoring System using chemcassette technology with a maximum of 24 points
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Vertex M helps facilities effectively safeguard against downtime by combining the most advanced Chemcassette® optics technologies and built-in system redundancies. Vertex M is a flexible, easy-to-use and reliable gas monitoring system. As your monitoring needs change, Vertex M expands its offering to as little as eight points and up to 24 points of continuous gas detection.
The Vertex system can accept sampling points up to 400 feet (120 meters) from the central unit. Vertex M can also accept a mix of universal analyzer modules and pyrolyzer analyzers. The system monitors a wide variety of gases present in semiconductor fabrication with sensitivity as low as parts per billion (ppb).
The Vertex system can accept sampling points up to 400 feet (120 meters) from the central unit. Vertex M can also accept a mix of universal analyzer modules and pyrolyzer analyzers. The system monitors a wide variety of gases present in semiconductor fabrication with sensitivity as low as parts per billion (ppb).
Even the best products deserve expert maintenance!
Elevate your gas detectors’ potential with Honeywell's expert maintenance services! Maximize uptime, eliminate costs, and ensure on-time, on-budget project completion.
Explore our fixed, portable, and high-tech support services now!
Specifications
Brand
- Brand
- Honeywell
Features
- Alarm Type
- Capable of A1 and A2 Alarms per Point, per Point Maintenance/Instrument Faults, as well as General Analyzer A1, General Analyzer A2, and General Analyzer Instrument/Maintenance Faults
- Visual Indicators
- 1024 x 768 pixel Touch Screen with at-a-Glance System Status
- Features & Benefits
- 8 to 24 Point Toxic Gas Monitor Configurable for Use with up to 3 Universal Chemcassette Analyzers or Combination 1 Pyrolyzer Analyzer/1 Universal Chemcassette Analyzer
- Display Type
- 1024 x 768 pixel Touch Screen with at-a-Glance System Status
Dimensions & Weight
- Size
- H: 56 in D: 36 in W: 24 in
- Sampling Distance
- Up to 400ft
- Exhaust Length
- 50 ft
Technical Specifications
- Sample Lines
- ID: 0.156 in OD: 1/4 in FEP Teflon
- ID: 0.190 in OD: 1/4 in FEP Teflon
- Relays
- Isolated (08X) or Non-Isolated (016X)
- PLC: 32 Relays for 8 Channel Isolated Relay Option; 64 Relays Total for 16 Channel Non-Isolated Relay Option
- Operating Altitude
- -1,000 ft to 6,000 ft Above Sea Level
- Network Interface
- OLE for Process Control (OPC) Interface
- Exhaust Line
- ID: 3/8 in OD: 1/2 in Polypropylene
- Digital Communication Ports
- ControlNet
- DF1
- DeviceNet
- Ethernet/CIP
- LonWorks
- ModBus Plus
- Modbus/TCP
- Profibus - DP
- Analog Outputs
- 4 to 20 mA (24 Channels)
Electrical Specifications
- Power Requirement
- 110/230 V AC
- Operating Voltage
- 110 or 230 V AC ± 10% (Under Load) @50/60 Hz; 15A
Operating Characteristics
- Operating Humidity
- 20 to 65% RH
Applications & Compatibility
- For Use With
- Universal Chemcassette Analyzers and Pyrolyzer Analyzer
Standards & Certifications
- Certificates and Standards
- CE Certified
- EN 300 330-1 V1.8.1
- EN 301 489-1 V1.9.2
- EN 50270:2015
- EN 61010-1:2010
- EN IEC 63000:2018
- EN ISO/IEC 17050-1:2010
- RoHS
Others
- Industry
- Manufacturing
Brand
- Brand
- Honeywell
Features
- Alarm Type
- Capable of A1 and A2 Alarms per Point, per Point Maintenance/Instrument Faults, as well as General Analyzer A1, General Analyzer A2, and General Analyzer Instrument/Maintenance Faults
- Visual Indicators
- 1024 x 768 pixel Touch Screen with at-a-Glance System Status
- Features & Benefits
- 8 to 24 Point Toxic Gas Monitor Configurable for Use with up to 3 Universal Chemcassette Analyzers or Combination 1 Pyrolyzer Analyzer/1 Universal Chemcassette Analyzer
- Display Type
- 1024 x 768 pixel Touch Screen with at-a-Glance System Status
Dimensions & Weight
- Size
- H: 56 in D: 36 in W: 24 in
- Sampling Distance
- Up to 400ft
- Exhaust Length
- 50 ft
Technical Specifications
- Sample Lines
- ID: 0.156 in OD: 1/4 in FEP Teflon
- ID: 0.190 in OD: 1/4 in FEP Teflon
- Relays
- Isolated (08X) or Non-Isolated (016X)
- PLC: 32 Relays for 8 Channel Isolated Relay Option; 64 Relays Total for 16 Channel Non-Isolated Relay Option
- Operating Altitude
- -1,000 ft to 6,000 ft Above Sea Level
- Network Interface
- OLE for Process Control (OPC) Interface
- Exhaust Line
- ID: 3/8 in OD: 1/2 in Polypropylene
- Digital Communication Ports
- ControlNet
- DF1
- DeviceNet
- Ethernet/CIP
- LonWorks
- ModBus Plus
- Modbus/TCP
- Profibus - DP
- Analog Outputs
- 4 to 20 mA (24 Channels)
Electrical Specifications
- Power Requirement
- 110/230 V AC
- Operating Voltage
- 110 or 230 V AC ± 10% (Under Load) @50/60 Hz; 15A
Operating Characteristics
- Operating Humidity
- 20 to 65% RH
Applications & Compatibility
- For Use With
- Universal Chemcassette Analyzers and Pyrolyzer Analyzer
Standards & Certifications
- Certificates and Standards
- CE Certified
- EN 300 330-1 V1.8.1
- EN 301 489-1 V1.9.2
- EN 50270:2015
- EN 61010-1:2010
- EN IEC 63000:2018
- EN ISO/IEC 17050-1:2010
- RoHS
Others
- Industry
- Manufacturing
- Brand : Honeywell
- Alarm Type : Capable of A1 and A2 Alarms per Point, per Point Maintenance/Instrument Faults, as well as General Analyzer A1, General Analyzer A2, and General Analyzer Instrument/Maintenance Faults
- Visual Indicators : 1024 x 768 pixel Touch Screen with at-a-Glance System Status
- Size : H: 56 in D: 36 in W: 24 in
- Sampling Distance : Up to 400ft
- Sample Lines : ID: 0.156 in OD: 1/4 in FEP Teflon|ID: 0.190 in OD: 1/4 in FEP Teflon
- Relays : Isolated (08X) or Non-Isolated (016X)|PLC: 32 Relays for 8 Channel Isolated Relay Option; 64 Relays Total for 16 Channel Non-Isolated Relay Option
- Power Requirement : 110/230 V AC
- Operating Voltage : 110 or 230 V AC ± 10% (Under Load) @50/60 Hz; 15A
- Operating Humidity : 20 to 65% RH
- Operating Altitude : -1,000 ft to 6,000 ft Above Sea Level
- Network Interface : OLE for Process Control (OPC) Interface
- Industry : Manufacturing
- For Use With : Universal Chemcassette Analyzers and Pyrolyzer Analyzer
- Features & Benefits : 8 to 24 Point Toxic Gas Monitor Configurable for Use with up to 3 Universal Chemcassette Analyzers or Combination 1 Pyrolyzer Analyzer/1 Universal Chemcassette Analyzer
- Exhaust Line : ID: 3/8 in OD: 1/2 in Polypropylene
- Exhaust Length : 50 ft
- Display Type : 1024 x 768 pixel Touch Screen with at-a-Glance System Status
- Digital Communication Ports : ControlNet|DF1|DeviceNet|Ethernet/CIP|LonWorks|ModBus Plus|Modbus/TCP|Profibus - DP
- Certificates and Standards : CE Certified|EN 300 330-1 V1.8.1|EN 301 489-1 V1.9.2|EN 50270:2015|EN 61010-1:2010|EN IEC 63000:2018|EN ISO/IEC 17050-1:2010|RoHS
- Analog Outputs : 4 to 20 mA (24 Channels)
