    Fixed Gas Detectors

    301IRF Refrigerant Gas Detector

    301IRF Refrigerant Gas Detector

    Overview
    Install Honeywell 301IRF sensor at low levels in chiller room for reliable detection of a variety of refrigerant gasses. Requires installation with a 301EM-20 controller.
    Product Overview:
    Discreet design and rugged ABS-Polycarbonate housing for the 301IRFS set the standard for “at the source” gas detection in a chiller room. Mount directly to the chiller pad or low on the wall in close proximity to achieve early notifications in the event of a refrigerant leak.
    ASHRAE No 15-2001 Mechanical Standard and B-52 Code Compliance. The ASHRAE and B-52 security standards have been established to minimize risk and protect the safety of mechanical room personnel and the environment at large. Honeywell’s 301IRF, together with the 301EM mechanical room controller, provides a complete solution that meets and even exceeds these rigorous standards. The 301EM can be configured to offer automatic fan, horn and strobe activation in addition to manual fan activation when the 301IRF detects a refrigerant.
    Additional Features and Benefits:
    User Friendly:
    • State-of-the-art infrared sensor technology
    • LED indicator
    • Low-profile and rugged construction for low mounting in chiller/mechanical room
    Economical Solution:
    • Cost-effective answer for installation in areas where refrigeration gas hazards may be present
    Detectable Gasses:
    • R11, R22, R123, R125, R134A, R404A, R407C, R410A, R448A, R449A, R507A, R513A, R514A, R4310, 1233ZD, 1234ZE.
    Features & Benefits:
    • Infrared sensing technology responds promptly
    • Low-profile design suited for mounting directly to chiller pad or low on nearby wall
    • Low maintenance
    Quick Specs:
    • Power requirement operates on 12 VDC power only
    • Dimensions 4” H x 11” W x 2.5” D (10.2 x 28 x 6.3 m)
    • Weight 2.33 lbs (0.603 kg)
    Specifications

    Brand

    • Brand
      • Honeywell

    Category

    • Sub-Category
      • Gas Detection Sensors & Transmitters

    Brand

    • Brand
      • Honeywell

    Category

    • Sub-Category
      • Gas Detection Sensors & Transmitters
    • Brand : Honeywell
    • Sub-Category : Gas Detection Sensors & Transmitters
    Manuals and Guides
    Name
    Description
    File Size
    Date
    Size
    301C, 301EM, 301AP, 301 IRFS Series Manual - English and French
    application/pdf 13.8 MB
    1/28/2022
    13.8 MB
    301C Controller Quick Start Guide
    application/pdf 3.24 MB
    2/3/2022
    3.24 MB
    Brochure
    Name
    Description
    File Size
    Date
    Size
    Mechanical Room Brochure
    application/pdf 1.59 MB
    2/7/2022
    1.59 MB
    Technical Note
    Name
    Description
    File Size
    Date
    Size
    301IRF Refrigerant Gas Detector Spec Sheet
    application/pdf 278.41 KB
    2/3/2022
    278.41 KB
    Name
    Description
    File Size
    Date
    Size
    301C, 301EM, 301AP, 301 IRFS Series Manual - English and French
    application/pdf 13.8 MB
    1/28/2022
    13.8 MB
    Mechanical Room Brochure
    application/pdf 1.59 MB
    2/7/2022
    1.59 MB
    301IRF Refrigerant Gas Detector Spec Sheet
    application/pdf 278.41 KB
    2/3/2022
    278.41 KB
    301C Controller Quick Start Guide
    application/pdf 3.24 MB
    2/3/2022
    3.24 MB
    Name
    Description
    File Size
    Date
    Size
    301C, 301EM, 301AP, 301 IRFS Series Manual - English and French
    13.8 MB
    1/28/2022
    301C Controller Quick Start Guide
    3.24 MB
    2/3/2022
    Mechanical Room Brochure
    1.59 MB
    2/7/2022
    301IRF Refrigerant Gas Detector Spec Sheet
    278.41 KB
    2/3/2022
