Air Purifying Respirator (APR)
7700 Series Half Mask
7700 Series Half Mask
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
The benchmark in half masks. Made from 100% medical grade silicone: the wide sealing area provides exceptional fit and comfort. Cradle suspension features woven straps that provide for maximum mobility without sacrificing support. Easily converts to PAPR or supplied air.
Features & Benefits:
• 770016 - Inhalation Cartridge Connector
• 770017 - Inhalation Valve Flap
• 770018 - Exhalation Valve Flap
• 770019 - Exhalation Valve Seat
• 770020 - Exhalation Valve Guard
• 770092 - Headband Assembly
Features & Benefits:
- Converts to PAPR or supplied air respirator. Latex free.
- Lower headstraps stretch and move with the worker for more comfort without pulling on the facepiece.
- The benchmark in half masks designed to provide maximum comfort: fit and performance.
- Upper headstraps have minimum give to provide secure support.
- Various thickness in sealing area for improved comfort and support - more support around the chin area and more flexibility on the nose bridge.
- Wide: contoured sealing area for great fit.
• 770016 - Inhalation Cartridge Connector
• 770017 - Inhalation Valve Flap
• 770018 - Exhalation Valve Flap
• 770019 - Exhalation Valve Seat
• 770020 - Exhalation Valve Guard
• 770092 - Headband Assembly
Specifications
Configuration
- Strap Style
- Adjustable Strap
- Filter System
- Double
- Cartridge Type
- N-Series
- Filtration Type
- N-Series
- Valve Type
- Exhalation Valve
- Inhalation Valve
Material
- Facepiece Material
- Medical Grade Silicone
- Latex free
- Yes
- Material
- Nylon
- Silicone
Standards & Certifications
- Standards
- NIOSH
- Cartridge/Filter Rating
- Type C
Protection
- Gas/Vapor Protection Type
- Yes
- Assigned Protection Factor
- 10: Air Purifying Half Mask
- 50: Continuous Flow Supplied Air Half Mask
- 50: Powered Air Purifying Half Mask
Dimension & Weight
- Weight
- 130 gram
- Mask Size
- Large
- Medium
- Small
Applicability
- For Use With
- Honeywell PA700 PAPR and Accompanying Cartridges and/or HEPA Filters
- Recommended Industry
- Pharmaceutical: Laboratories
Other
- Color
- Blue
- Brand
- Honeywell North
- Product Series
- 7700 Series
- Disposable/Reusable
- Reusable
Features & Benefits
- Features & Benefits
- Dual Elasticity Headstraps Provide a Secure and Flexible Fit. Medical-Grade Silicone Facepiece Provides a Soft-Comfortable Fit. Wide Contoured Sealing Area Fits a Wide Variety of Facial Types. Variable Thickness In Sealing Area Provides The Optimal Amount of Seal On Each Area of The Face for Superior Comfort Without Sacrificing Fit. Niosh Approved with Backpack Adapter-Ideal for Welding and Painting. Niosh Approved with Papr and Supplied Air To Offer Flexibility In The Workplace. Only 9 Replacement Parts-for Quick and Easy Strip Down and Clean. Both Masks Are Latex Free-No Need To Be Concerned About Latex Allergens. Strategically Engineered Exhalation Valve Placement Allows More Breath To Be Exhaled Faster-Making The Mask More Comfortable and Cooler To Wear. Made From 100% Medical Grade Silicone-The Wide Sealing Area Provides Exceptional Fit and Comfort. Cradle Suspension Features Woven Straps That Provide for Maximum Mobility Without Sacrificing Support.
Configuration
- Strap Style
- Adjustable Strap
- Filter System
- Double
- Cartridge Type
- N-Series
- Filtration Type
- N-Series
- Valve Type
- Exhalation Valve
- Inhalation Valve
Material
- Facepiece Material
- Medical Grade Silicone
- Latex free
- Yes
- Material
- Nylon
- Silicone
Standards & Certifications
- Standards
- NIOSH
- Cartridge/Filter Rating
- Type C
Protection
- Gas/Vapor Protection Type
- Yes
- Assigned Protection Factor
- 10: Air Purifying Half Mask
- 50: Continuous Flow Supplied Air Half Mask
- 50: Powered Air Purifying Half Mask
Dimension & Weight
- Weight
- 130 gram
- Mask Size
- Large
- Medium
- Small
Applicability
- For Use With
- Honeywell PA700 PAPR and Accompanying Cartridges and/or HEPA Filters
- Recommended Industry
- Pharmaceutical: Laboratories
Other
- Color
- Blue
- Brand
- Honeywell North
- Product Series
- 7700 Series
- Disposable/Reusable
- Reusable
Features & Benefits
- Features & Benefits
- Dual Elasticity Headstraps Provide a Secure and Flexible Fit. Medical-Grade Silicone Facepiece Provides a Soft-Comfortable Fit. Wide Contoured Sealing Area Fits a Wide Variety of Facial Types. Variable Thickness In Sealing Area Provides The Optimal Amount of Seal On Each Area of The Face for Superior Comfort Without Sacrificing Fit. Niosh Approved with Backpack Adapter-Ideal for Welding and Painting. Niosh Approved with Papr and Supplied Air To Offer Flexibility In The Workplace. Only 9 Replacement Parts-for Quick and Easy Strip Down and Clean. Both Masks Are Latex Free-No Need To Be Concerned About Latex Allergens. Strategically Engineered Exhalation Valve Placement Allows More Breath To Be Exhaled Faster-Making The Mask More Comfortable and Cooler To Wear. Made From 100% Medical Grade Silicone-The Wide Sealing Area Provides Exceptional Fit and Comfort. Cradle Suspension Features Woven Straps That Provide for Maximum Mobility Without Sacrificing Support.
- Filter System : Double
- Valve Type : Exhalation Valve|Inhalation Valve
- Filtration Type : N-Series
- Cartridge Type : N-Series
- Strap Style : Adjustable Strap
- Latex free : Yes
- Facepiece Material : Medical Grade Silicone
- Material : Nylon|Silicone
- Cartridge/Filter Rating : Type C
- Standards : NIOSH
- Gas/Vapor Protection Type : Yes
- Assigned Protection Factor : 10: Air Purifying Half Mask|50: Continuous Flow Supplied Air Half Mask|50: Powered Air Purifying Half Mask
- Mask Size : Large|Medium|Small
- Weight : 130 gram
- For Use With : Honeywell PA700 PAPR and Accompanying Cartridges and/or HEPA Filters
- Recommended Industry : Pharmaceutical: Laboratories
- Disposable/Reusable : Reusable
- Brand : Honeywell North
- Color : Blue
- Product Series : 7700 Series
- Features & Benefits : Dual Elasticity Headstraps Provide a Secure and Flexible Fit. Medical-Grade Silicone Facepiece Provides a Soft-Comfortable Fit. Wide Contoured Sealing Area Fits a Wide Variety of Facial Types. Variable Thickness In Sealing Area Provides The Optimal Amount of Seal On Each Area of The Face for Superior Comfort Without Sacrificing Fit. Niosh Approved with Backpack Adapter-Ideal for Welding and Painting. Niosh Approved with Papr and Supplied Air To Offer Flexibility In The Workplace. Only 9 Replacement Parts-for Quick and Easy Strip Down and Clean. Both Masks Are Latex Free-No Need To Be Concerned About Latex Allergens. Strategically Engineered Exhalation Valve Placement Allows More Breath To Be Exhaled Faster-Making The Mask More Comfortable and Cooler To Wear. Made From 100% Medical Grade Silicone-The Wide Sealing Area Provides Exceptional Fit and Comfort. Cradle Suspension Features Woven Straps That Provide for Maximum Mobility Without Sacrificing Support.
Data Sheet
Name
Description
File Size
Date
Size
7700 Series Half Mask Data Sheet.pdf
application/pdf 176.09 KB
11/2/2021
176.09 KB
Brief
Name
Description
File Size
Date
Size
7700 Series Half Mask Tech Brief
application/pdf 1.6 MB
3/26/2024
1.6 MB
Name
Description
File Size
Date
Size
7700 Series Half Mask Data Sheet.pdf
application/pdf 176.09 KB
11/2/2021
176.09 KB
7700 Series Half Mask Tech Brief
application/pdf 1.6 MB
3/26/2024
1.6 MB
Name
Description
File Size
Date
Size
Product Number
Please sign in to view part numbers available for purchase based on your account Sign In
Part Number
Description
Leaf Category
Thumbnail
Add to list
770030AL
HALF MASK 7700 AUNZ LG
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030AL
HALF MASK 7700 AUNZ LG
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030AM
HALF MASK 7700 AUNZ MED
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030AM
HALF MASK 7700 AUNZ MED
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030AS
HALF MASK 7700 AUNZ SM
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030AS
HALF MASK 7700 AUNZ SM
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030L
North 7700 half mask silicone with dual cartridge connectors for N series. Size Large.
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030L
North 7700 half mask silicone with dual cartridge connectors for N series. Size Large.
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030M
North 7700 half mask silicone with dual cartridge connectors for N series. Size Medium.
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030M
North 7700 half mask silicone with dual cartridge connectors for N series. Size Medium.
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
770030S
North 7700 half mask silicone with dual cartridge connectors for N series. Size Small.
https://honeywell.scene7.com/is/image/Honeywell65/770030
770030S
North 7700 half mask silicone with dual cartridge connectors for N series. Size Small.
https://honeywell.scene7.com/is/image/Honeywell65/770030
N65770014
N7700,Rd40,S
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
N65770014
N7700,Rd40,S
https://s7d1.scene7.com/is/image/Honeywell65/7700-series-half-mask
