    Transportable Area Monitoring

    AreaRAE Plus

    Transportable area monitor for multiple threat detection

    Overview
    Support Where To Buy Contact Us
    The AreaRAE Plus provides superior detection of toxic and combustible gases, VOCs and wind speed, direction and humidity—all in one easy-to configure device. Plus, you’ll have vital details about threats happening in real-time—arming you with the information you need to act quickly.Features and Benefits:
    • Monitors up to seven threats, including VOCs, combustibles, Toxics and Oxygen
    • Optional meteorological sensor for tracking toxic plumes
    • 7R+ photoionization detector (PID) for monitoring VOCs at parts per million
    • Secondary radio module (Mesh) act as an communication Hub for other wireless devices
    • Ruggedized, portable, and weather-resistant design for harsh environments
    • Part of ConneXt Safety Solutions with ISM and Wi-Fi wireless configurations
    Application:
    • Confined Space Entry
    • Environmental Cleanups/ Remediation
    • Fence Line Monitoring
    • Leak Detection
    • Plant Shutdown & Turn-Around
    Even the best products deserve expert maintenance!

    Elevate your gas detectors’ potential with Honeywell's expert maintenance services! Maximize uptime, eliminate costs, and ensure on-time, on-budget project completion.

    Explore our fixed, portable, and high-tech support services now!

    Specifications

    Overview

    • Brand
      • RAE
    • Warranty
      • Four years for O2 Liquid Oxygen sensors

    Features

    • Sub-Category
      • Transportable
    • Alarm Type
      • Audible, Visual, Vibrating
    • Datalogging
      • Continuous data logging (90 days for 7 gas sensors, 1 Gamma
    • Features & Benefits
      • Delivers real-time readings to Honeywell’s remote monitoring software, so you can instantly determine the location and severity of a threat
    • User Options
      • 3 operation and programming keys
    • Wireless Technology
      • BLE, MESH, WiFi, LORA

    Dimensions & Weight

    • Instrument Size
      • 12.36” x 12.04” x 6.53”

    Technical Specifications

    • Humidity Range
      • 0%-95%
    • Sensor Range
      • VOC (0-2000ppm), LEL (0-100%LEL), CO2 (0-50000ppm), NH3 (0-100ppm), CO (0-2000ppm), Cl2 (0-50ppm), ETO (0-500ppm), H2 (0-2000ppm), HCL (0-15ppm), HCN (0-50ppm), HF (0.5-10ppm), H2S (0-1000ppm), O2 (0-30%), SO2 (0-20ppm), NO (0-250ppm), NO2 (0-20ppm), PH3 (0-20ppm)
    • Gas Type
      • VOC, LEL, CO2, NH3, CO, Cl2, ETO, H2, HCL, HCN, HF, H2S, O2, SO2, NO, NO2, PH3

    Battery & Charging

    • Battery Run Time
      • 20

    Standards & Certifications

    • Standards
      • US and Canada: Class 1, Division 2, Groups A, B, C, D
    • Ingress Protection
      • IP65

    Others

    • Sampling Pump Range
      • 100ft (30m)
    • Minimum Temperature
      • -20 degree Celsius
      • -4 degree Fahrenheit
    • Maximum Temperature
      • 140 degree Fahrenheit
      • 60 degree Celsius
    • Weight
      • 14.33 US Pound
      • 6.5 kilogram

    Overview

    • Brand
      • RAE
    • Warranty
      • Four years for O2 Liquid Oxygen sensors

    Features

    • Sub-Category
      • Transportable
    • Alarm Type
      • Audible, Visual, Vibrating
    • Datalogging
      • Continuous data logging (90 days for 7 gas sensors, 1 Gamma
    • Features & Benefits
      • Delivers real-time readings to Honeywell’s remote monitoring software, so you can instantly determine the location and severity of a threat
    • User Options
      • 3 operation and programming keys
    • Wireless Technology
      • BLE, MESH, WiFi, LORA

    Dimensions & Weight

    • Instrument Size
      • 12.36” x 12.04” x 6.53”

    Technical Specifications

    • Humidity Range
      • 0%-95%
    • Sensor Range
      • VOC (0-2000ppm), LEL (0-100%LEL), CO2 (0-50000ppm), NH3 (0-100ppm), CO (0-2000ppm), Cl2 (0-50ppm), ETO (0-500ppm), H2 (0-2000ppm), HCL (0-15ppm), HCN (0-50ppm), HF (0.5-10ppm), H2S (0-1000ppm), O2 (0-30%), SO2 (0-20ppm), NO (0-250ppm), NO2 (0-20ppm), PH3 (0-20ppm)
    • Gas Type
      • VOC, LEL, CO2, NH3, CO, Cl2, ETO, H2, HCL, HCN, HF, H2S, O2, SO2, NO, NO2, PH3

    Battery & Charging

    • Battery Run Time
      • 20

    Standards & Certifications

    • Standards
      • US and Canada: Class 1, Division 2, Groups A, B, C, D
    • Ingress Protection
      • IP65

    Others

    • Sampling Pump Range
      • 100ft (30m)
    • Minimum Temperature
      • -20 degree Celsius
      • -4 degree Fahrenheit
    • Maximum Temperature
      • 140 degree Fahrenheit
      • 60 degree Celsius
    • Weight
      • 14.33 US Pound
      • 6.5 kilogram
    • Brand : RAE
    • Sampling Pump Range : 100ft (30m)
    • Minimum Temperature : -20 degree Celsius|-4 degree Fahrenheit
    • Maximum Temperature : 140 degree Fahrenheit|60 degree Celsius
    • Weight : 14.33 US Pound|6.5 kilogram
    • Sub-Category : Transportable
    • Instrument Size : 12.36” x 12.04” x 6.53”
    • Humidity Range : 0%-95%
    • Sensor Range : VOC (0-2000ppm), LEL (0-100%LEL), CO2 (0-50000ppm), NH3 (0-100ppm), CO (0-2000ppm), Cl2 (0-50ppm), ETO (0-500ppm), H2 (0-2000ppm), HCL (0-15ppm), HCN (0-50ppm), HF (0.5-10ppm), H2S (0-1000ppm), O2 (0-30%), SO2 (0-20ppm), NO (0-250ppm), NO2 (0-20ppm), PH3 (0-20ppm)
    • Alarm Type : Audible, Visual, Vibrating
    • Battery Run Time : 20
    • Standards : US and Canada: Class 1, Division 2, Groups A, B, C, D
    • Datalogging : Continuous data logging (90 days for 7 gas sensors, 1 Gamma
    • Features & Benefits : Delivers real-time readings to Honeywell’s remote monitoring software, so you can instantly determine the location and severity of a threat
    • User Options : 3 operation and programming keys
    • Warranty : Four years for O2 Liquid Oxygen sensors
    • Wireless Technology : BLE, MESH, WiFi, LORA
    • Ingress Protection : IP65
    • Gas Type : VOC, LEL, CO2, NH3, CO, Cl2, ETO, H2, HCL, HCN, HF, H2S, O2, SO2, NO, NO2, PH3
