Handheld Computers
CT30 XP Handheld Computer
The CT30 XP is a durable, all-purpose business tool ensuring ultra-reliable data access and communications for front-line mobile workers.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
- Built on the Mobility Edge™ platform, a durable, stable and secure foundation for effective, long-lasting solutions.
- Octa-core processor with new Qualcomm® 3rd-generation artificial intelligence (AI) engine and higher-powered graphics processing unit.
- Can be empowered further with Honeywell Smart Pay, Operational Intelligence, and Smart Talk Unified Communication software.
- The FlexRange™ scan engine empowers your workforce to scan barcodes with pinpoint accuracy and speed. From 10 cm to 20 m, the FlexRange engine can scan items near and far, high and low, and can precisely capture data from damaged or low visibility barcodes.
- Powered by an easy-to-replace, warm-swap, 3,400-mAh battery for uninterrupted use.
- Design based on user feedback, including a vivid, 5.5-inch (14 cm), full-high-definition (FHD) screen into a slim, lightweight, yet durable package.
- Support for Wi-Fi 6 in selected SKUs increases connection reliability, range and throughput in crowded conditions and provides a better experience on voice or video communications.
- Bluetooth® version 5.1 availability includes a variety of power saving features as well as angle-of-arrival-based direction-finding capabilities.
- Guaranteed support from Android 11 to at least Android 13 and committed support for Android 14 and 15, subject to feasibility.
Features
- Housing Grade
- Disinfectant Ready Housing
- For Use With
- Android
- Application
- Soft Goods Retail, General Merchandise and Healthcare
- Features
- Compatible with Universal Dock
- Camera
- 13-megapixel rear camera
- 8-megapixel front camera
- Camera Position
- Front and Rear
Dimensions
- Overall Dimensions
- 154 mm x 76 mm x 12.6 mm
- 6.06 in x 2.99 in x 0.50 in
Scanning Specifications
- Decode Capability
- 1D/2D Barcode Symbologies
Network
- Bluetooth Specifications
- V5.1 Bluetooth and BLE; 2nd BLE availble on all SKUs except CT30P-XXX-XXXXXNX . Bluetooth profiles includes HFP, PBAP, A2DP, AVRCP, OPP, SPP, GATT
- WWAN Specifications
- AT&T FirstNet Compliant
- GSM: 850, 900, 1800, 1900 (Quad Bands)
- LTE: Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 66, 71
- UMTS/HSPA+ (3G): Bands 1, 2, 4, 5, 6, 8, 9, 19
- Up to 390 Mbps CAT13 LTE downlink and up to 75 Mbps CAT5 LTE uplink:
- WWAN Radio (ATT/VZW/SPRINT/TMO/NA/EU)
- WLAN Specifications
- All SKUs: 802.11 d/e/h/i/k/r/v/u/w/mc
- All other configurations: IEEE 802.11 a/b/g/n/ac; All SKUs: 802.11 d/e/h/i/k/r/v/u/w/mc
- CT30P-L0N, CT30P-L1N: Wi-Fi 5, IEEE 802.11 a/b/g/n/ac
- CT30P-X0N: Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax and 2x2 MU-MIMO
- RFID Specifications
- Integrated NFC reader, compliant with ISO/IEC 14443 A, ISO/IEC 14443 B, ISO/IEC 15693 (ICode), MIFARE 1K / 4K, MIFARE DESFire, Sony FeliCa, ISO/IEC 18092 (Type F)
- GPS Specifications
- Simultaneous GNSS Receiver Support for GPS, GLONASS, Galileo and BeiDou
Software & Firmware
- Operating System
- Each Android version guaranteed from Android 11 to at least 13, committed support for Android 14 and Android 15, pending feasibility
- Operating System Type
- Android
- Platform
- Mobility Edge
Memory & Data
- Memory
- 6GB DDR4x RAM, 64GB UFS Flash; 4GB DDR4x RAM, 64GB UFS Flash
Hardware
- Display Resolution
- Full High-Definition (2160 x 1080)
- Scan Engine Model
- Honeywell S0703 VE; Honeywell FlexRange
- Scan Engine Type
- Laser aimer
- Display Size
- 13.97 cm (5.5 in)
- Processor
- Qualcomm QCS4290/QCM4290 octa-core, 2.0GHz
- Keyboard
- Touchscreen
Electrical
- Battery Capacity
- 3400mAh
- Battery Types
- Replaceable between shifts; Warm-swappable
- Battery Type
- Li-Ion; smart battery with integrated diagnostics tools
Environmental
- Storage Temperature Range
- -22°F to 158°F
- -30°C to 70°C
- Operating Temperature
- -10°C to 50°C (14°F to 122°F)
- Operating Humidity
- 5% to 95% (non-condensing)
Standards & Approvals
- Tumble Specifications
- Exceeds 500 0.5 m (1.64 ft) tumbles per IEC 60068-2-32 specification
- Drop Specifications
- 1.2 m (4 ft) to concrete at through operating temperature per MIL-STD 810H; 1.5m (5ft ) to concret at room temperature per MIL-STD 810H.
- Protection Ratings
- IP67
Service Terms
- Warranty Duration
- LTE Advanced Support
- One-year factory warranty
ERP
- Brand
- Honeywell
Others
- Connectivity
- Wi-Fi
- Wi-Fi & Cellular
- Environment
- Healthcare
- Standard
- Keypad
- Full Touchscreen
Features
- Housing Grade
- Disinfectant Ready Housing
- For Use With
- Android
- Application
- Soft Goods Retail, General Merchandise and Healthcare
- Features
- Compatible with Universal Dock
- Camera
- 13-megapixel rear camera
- 8-megapixel front camera
- Camera Position
- Front and Rear
Dimensions
- Overall Dimensions
- 154 mm x 76 mm x 12.6 mm
- 6.06 in x 2.99 in x 0.50 in
Scanning Specifications
- Decode Capability
- 1D/2D Barcode Symbologies
Network
- Bluetooth Specifications
- V5.1 Bluetooth and BLE; 2nd BLE availble on all SKUs except CT30P-XXX-XXXXXNX . Bluetooth profiles includes HFP, PBAP, A2DP, AVRCP, OPP, SPP, GATT
- WWAN Specifications
- AT&T FirstNet Compliant
- GSM: 850, 900, 1800, 1900 (Quad Bands)
- LTE: Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 66, 71
- UMTS/HSPA+ (3G): Bands 1, 2, 4, 5, 6, 8, 9, 19
- Up to 390 Mbps CAT13 LTE downlink and up to 75 Mbps CAT5 LTE uplink:
- WWAN Radio (ATT/VZW/SPRINT/TMO/NA/EU)
- WLAN Specifications
- All SKUs: 802.11 d/e/h/i/k/r/v/u/w/mc
- All other configurations: IEEE 802.11 a/b/g/n/ac; All SKUs: 802.11 d/e/h/i/k/r/v/u/w/mc
- CT30P-L0N, CT30P-L1N: Wi-Fi 5, IEEE 802.11 a/b/g/n/ac
- CT30P-X0N: Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax and 2x2 MU-MIMO
- RFID Specifications
- Integrated NFC reader, compliant with ISO/IEC 14443 A, ISO/IEC 14443 B, ISO/IEC 15693 (ICode), MIFARE 1K / 4K, MIFARE DESFire, Sony FeliCa, ISO/IEC 18092 (Type F)
- GPS Specifications
- Simultaneous GNSS Receiver Support for GPS, GLONASS, Galileo and BeiDou
Software & Firmware
- Operating System
- Each Android version guaranteed from Android 11 to at least 13, committed support for Android 14 and Android 15, pending feasibility
- Operating System Type
- Android
- Platform
- Mobility Edge
Memory & Data
- Memory
- 6GB DDR4x RAM, 64GB UFS Flash; 4GB DDR4x RAM, 64GB UFS Flash
Hardware
- Display Resolution
- Full High-Definition (2160 x 1080)
- Scan Engine Model
- Honeywell S0703 VE; Honeywell FlexRange
- Scan Engine Type
- Laser aimer
- Display Size
- 13.97 cm (5.5 in)
- Processor
- Qualcomm QCS4290/QCM4290 octa-core, 2.0GHz
- Keyboard
- Touchscreen
Electrical
- Battery Capacity
- 3400mAh
- Battery Types
- Replaceable between shifts; Warm-swappable
- Battery Type
- Li-Ion; smart battery with integrated diagnostics tools
Environmental
- Storage Temperature Range
- -22°F to 158°F
- -30°C to 70°C
- Operating Temperature
- -10°C to 50°C (14°F to 122°F)
- Operating Humidity
- 5% to 95% (non-condensing)
Standards & Approvals
- Tumble Specifications
- Exceeds 500 0.5 m (1.64 ft) tumbles per IEC 60068-2-32 specification
- Drop Specifications
- 1.2 m (4 ft) to concrete at through operating temperature per MIL-STD 810H; 1.5m (5ft ) to concret at room temperature per MIL-STD 810H.
- Protection Ratings
- IP67
Service Terms
- Warranty Duration
- LTE Advanced Support
- One-year factory warranty
ERP
- Brand
- Honeywell
Others
- Connectivity
- Wi-Fi
- Wi-Fi & Cellular
- Environment
- Healthcare
- Standard
- Keypad
- Full Touchscreen
- Housing Grade : Disinfectant Ready Housing|
- For Use With : Android|
- Application : Soft Goods Retail, General Merchandise and Healthcare|
- Features : Compatible with Universal Dock|
- Camera : 13-megapixel rear camera|8-megapixel front camera|
- Overall Dimensions : 154 mm x 76 mm x 12.6 mm|6.06 in x 2.99 in x 0.50 in|
- Decode Capability : 1D/2D Barcode Symbologies|
- Bluetooth Specifications : V5.1 Bluetooth and BLE; 2nd BLE availble on all SKUs except CT30P-XXX-XXXXXNX . Bluetooth profiles includes HFP, PBAP, A2DP, AVRCP, OPP, SPP, GATT|
- WWAN Specifications : AT&T FirstNet Compliant|GSM: 850, 900, 1800, 1900 (Quad Bands)|LTE: Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 66, 71|UMTS/HSPA+ (3G): Bands 1, 2, 4, 5, 6, 8, 9, 19|Up to 390 Mbps CAT13 LTE downlink and up to 75 Mbps CAT5 LTE uplink:|WWAN Radio (ATT/VZW/SPRINT/TMO/NA/EU)|
- WLAN Specifications : All SKUs: 802.11 d/e/h/i/k/r/v/u/w/mc|All other configurations: IEEE 802.11 a/b/g/n/ac; All SKUs: 802.11 d/e/h/i/k/r/v/u/w/mc|CT30P-L0N, CT30P-L1N: Wi-Fi 5, IEEE 802.11 a/b/g/n/ac|CT30P-X0N: Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax and 2x2 MU-MIMO|
- RFID Specifications : Integrated NFC reader, compliant with ISO/IEC 14443 A, ISO/IEC 14443 B, ISO/IEC 15693 (ICode), MIFARE 1K / 4K, MIFARE DESFire, Sony FeliCa, ISO/IEC 18092 (Type F)|
- GPS Specifications : Simultaneous GNSS Receiver Support for GPS, GLONASS, Galileo and BeiDou|
- Operating System : Each Android version guaranteed from Android 11 to at least 13, committed support for Android 14 and Android 15, pending feasibility|
- Memory : 6GB DDR4x RAM, 64GB UFS Flash; 4GB DDR4x RAM, 64GB UFS Flash|
- Display Resolution : Full High-Definition (2160 x 1080)|
- Scan Engine Model : Honeywell S0703 VE; Honeywell FlexRange|
- Scan Engine Type : Laser aimer|
- Display Size : 13.97 cm (5.5 in)|
- Processor : Qualcomm QCS4290/QCM4290 octa-core, 2.0GHz|
- Battery Capacity : 3400mAh|
- Battery Types : Replaceable between shifts; Warm-swappable|
- Battery Type : Li-Ion; smart battery with integrated diagnostics tools|
- Storage Temperature Range : -22°F to 158°F|-30°C to 70°C|
- Operating Temperature : -10°C to 50°C (14°F to 122°F)|
- Operating Humidity : 5% to 95% (non-condensing)|
- Tumble Specifications : Exceeds 500 0.5 m (1.64 ft) tumbles per IEC 60068-2-32 specification|
- Drop Specifications : 1.2 m (4 ft) to concrete at through operating temperature per MIL-STD 810H; 1.5m (5ft ) to concret at room temperature per MIL-STD 810H.|
- Protection Ratings : IP67|
- Warranty Duration : LTE Advanced Support|One-year factory warranty|
- Brand : Honeywell|
- Operating System Type : Android|
- Camera Position : Front and Rear|
- Connectivity : Wi-Fi|Wi-Fi & Cellular|
- Environment : Healthcare|Standard|
- Platform : Mobility Edge|
- Keyboard : Touchscreen|
- Keypad : Full Touchscreen|
