Touchpoint™ Plus Wireless Controller
Multi-channel command and control center for MeshGuard network
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
The Touchpoint™ Plus Wireless is a hybrid multi-channel controller with a built-in wireless modem that is designed for integration with RAE Systems by Honeywell MeshGuard intelligent network of connected sensors combined with traditional hard wired sensors. It is the command-and-control element of the wireless gas detection system that gathers data, monitors and activate alarms from MeshGuard toxic, flammable gas and flame detection monitors.
Features and Benefits:
Features and Benefits:
- Quick and easy installation
- Simple, intuitive operation
- Rugged and reliable
- Flexible to handle a variety of data processing and communication needs
- Manages up to 64 wireless channels
- 8 analogue 4-20mA inputs
- Up to 14 programmable relay outputs
- Touchscreen LCD
- Exploration
- Fracking
- Plant Shutdown & Turn-Around
Even the best products deserve expert maintenance!
Elevate your gas detectors’ potential with Honeywell's expert maintenance services! Maximize uptime, eliminate costs, and ensure on-time, on-budget project completion.
Explore our fixed, portable, and high-tech support services now!
Specifications
Brand
- Brand
- RAE
- RAE
Category
- Sub-Category
- Gas Detection Controllers
- Gas Detection Controllers
Dimension & Weight
- Weight range
- 8500 gram
Range
- Humidity Range
- 10 to 95% RH (Non-Condensing) percent
Temperature
- Storage Temperature
- -25 to +60°C
Alarm
- Alarm Included
- Yes
- Alarm Type
- Audible Alarm
Certifications
- Certifications - Hazloc
- Class I, Div.2, Groups A, B, C and D, or Non-Hazardous Only
Datalogging
- Datalogging Capable
- Yes
- Datalogging
- Configuration and Logged Events
Display
- Display Viewing Area
- H: 155.08 mm V: 86.92 mm
- Display Included
- Yes
- Display Matrix
- 800 x 480 pixel
- Display Type
- LCD
Features & Benefits
- Features & Benefits
- Backup Battery for up to 12 Hours of Operation Depending on Configuration
- Built-In Data Logging, C1D2 Certified
- Built-In Wireless Modem for Use in Meshguard Networks
- Flexible to Handle a Variety of Data Processing and Communication Needs
- Manages up to 64 Channels and up to 14 Programmable SPDT Relay Outputs
- Quick and Easy Installation
- RS-485 and Ethernet Interface,
- Rugged and Reliable
- Simple, Intuitive Operation
Material
- Material
- Polycarbonate ABS
Port
- Number of Digital Communication Ports
- 8
- Communication Ports
- MODBUS TCP, WEB Monitoring, and MODBUS RTU
- RS-485
Relay
- Relay Output Configuration
- 1.7A, 30V DC or 250V AC
- Relay Included
- Yes
Sensor
- Number of Sensor Inputs
- 8
Additional Specifications
- Number of Relay Outputs
- Up to 14 Programmable SPDT
- Visual Indicators
- 3 LEDs for Master Indicators
- Alarm: Red
- Fault: Yellow
- Normal: Green
- Response Time
- 3 second (time unit)
- NEMA Rating
- NEMA 4x
- Shielded
- Shielded
- Gas Type
- Toxic (0) O2 (1) Flammable (2) Flame (3)
- Graphic
- Yes
Dimensions & Weight
- Size
- 16.77 in × 11.81 in × 6.14 in
Technical Specifications
- Operating Frequency Range
- 2.400 to 2.4835 GHz
- Common Alarm Relay
- (3) 1.7 A, 30V DC or 250V AC
- Outputs
- 3 Common Alarm Outputs
- 4 Powered A/V Outputs for Alarms and Fault
Standards & Certifications
- Ingress Protection
- IP65
- Approvals
- CSA-C22.2 No. 61010-1-04
- EMC/RFI (EN 50270:2015)
- LVD (EN 61010-1:2010)
- UL 61010-1 (3rd Edition) and 508
Electrical Specifications
- Power Requirement
- 110/220 VAC, 105 W, 18 to 32 VDC (+/-10%) Typical 24 VDC
Applications & Compatibility
- Application
- Drilling Rigs and Petrochemical Plants
- Industrial Safety, Exploration, Fracking, Plant Shutdown & Turn-Around
- Steel Mills
- Tank Farms, Shipyards and Maritime
Overview
- Warranty
- 12 Months or 18 Months
Others
- Industry
- Energy
Brand
- Brand
- RAE
- RAE
Category
- Sub-Category
- Gas Detection Controllers
- Gas Detection Controllers
Dimension & Weight
- Weight range
- 8500 gram
Range
- Humidity Range
- 10 to 95% RH (Non-Condensing) percent
Temperature
- Storage Temperature
- -25 to +60°C
Alarm
- Alarm Included
- Yes
- Alarm Type
- Audible Alarm
Certifications
- Certifications - Hazloc
- Class I, Div.2, Groups A, B, C and D, or Non-Hazardous Only
Datalogging
- Datalogging Capable
- Yes
- Datalogging
- Configuration and Logged Events
Display
- Display Viewing Area
- H: 155.08 mm V: 86.92 mm
- Display Included
- Yes
- Display Matrix
- 800 x 480 pixel
- Display Type
- LCD
Features & Benefits
- Features & Benefits
- Backup Battery for up to 12 Hours of Operation Depending on Configuration
- Built-In Data Logging, C1D2 Certified
- Built-In Wireless Modem for Use in Meshguard Networks
- Flexible to Handle a Variety of Data Processing and Communication Needs
- Manages up to 64 Channels and up to 14 Programmable SPDT Relay Outputs
- Quick and Easy Installation
- RS-485 and Ethernet Interface,
- Rugged and Reliable
- Simple, Intuitive Operation
Material
- Material
- Polycarbonate ABS
Port
- Number of Digital Communication Ports
- 8
- Communication Ports
- MODBUS TCP, WEB Monitoring, and MODBUS RTU
- RS-485
Relay
- Relay Output Configuration
- 1.7A, 30V DC or 250V AC
- Relay Included
- Yes
Sensor
- Number of Sensor Inputs
- 8
Additional Specifications
- Number of Relay Outputs
- Up to 14 Programmable SPDT
- Visual Indicators
- 3 LEDs for Master Indicators
- Alarm: Red
- Fault: Yellow
- Normal: Green
- Response Time
- 3 second (time unit)
- NEMA Rating
- NEMA 4x
- Shielded
- Shielded
- Gas Type
- Toxic (0) O2 (1) Flammable (2) Flame (3)
- Graphic
- Yes
Dimensions & Weight
- Size
- 16.77 in × 11.81 in × 6.14 in
Technical Specifications
- Operating Frequency Range
- 2.400 to 2.4835 GHz
- Common Alarm Relay
- (3) 1.7 A, 30V DC or 250V AC
- Outputs
- 3 Common Alarm Outputs
- 4 Powered A/V Outputs for Alarms and Fault
Standards & Certifications
- Ingress Protection
- IP65
- Approvals
- CSA-C22.2 No. 61010-1-04
- EMC/RFI (EN 50270:2015)
- LVD (EN 61010-1:2010)
- UL 61010-1 (3rd Edition) and 508
Electrical Specifications
- Power Requirement
- 110/220 VAC, 105 W, 18 to 32 VDC (+/-10%) Typical 24 VDC
Applications & Compatibility
- Application
- Drilling Rigs and Petrochemical Plants
- Industrial Safety, Exploration, Fracking, Plant Shutdown & Turn-Around
- Steel Mills
- Tank Farms, Shipyards and Maritime
Overview
- Warranty
- 12 Months or 18 Months
Others
- Industry
- Energy
- Brand : RAE|RAE
- Sub-Category : Gas Detection Controllers|Gas Detection Controllers
- Weight range : 8500 gram
- Humidity Range : 10 to 95% RH (Non-Condensing) percent
- Storage Temperature : -25 to +60°C
- Alarm Included : Yes
- Alarm Type : Audible Alarm
- Certifications - Hazloc : Class I, Div.2, Groups A, B, C and D, or Non-Hazardous Only
- Datalogging Capable : Yes
- Datalogging : Configuration and Logged Events
- Display Viewing Area : H: 155.08 mm V: 86.92 mm
- Display Included : Yes
- Display Matrix : 800 x 480 pixel
- Display Type : LCD
- Features & Benefits : Backup Battery for up to 12 Hours of Operation Depending on Configuration|Built-In Data Logging, C1D2 Certified|Built-In Wireless Modem for Use in Meshguard Networks|Flexible to Handle a Variety of Data Processing and Communication Needs|Manages up to 64 Channels and up to 14 Programmable SPDT Relay Outputs|Quick and Easy Installation|RS-485 and Ethernet Interface,|Rugged and Reliable|Simple, Intuitive Operation
- Material : Polycarbonate ABS
- Number of Digital Communication Ports : 8
- Communication Ports : MODBUS TCP, WEB Monitoring, and MODBUS RTU|RS-485
- Relay Output Configuration : 1.7A, 30V DC or 250V AC
- Relay Included : Yes
- Number of Sensor Inputs : 8
- Number of Relay Outputs : Up to 14 Programmable SPDT
- Visual Indicators : 3 LEDs for Master Indicators|Alarm: Red|Fault: Yellow|Normal: Green
- Response Time : 3 second (time unit)
- NEMA Rating : NEMA 4x
- Shielded : Shielded
- Gas Type : Toxic (0) O2 (1) Flammable (2) Flame (3)
- Graphic : Yes
- Size : 16.77 in × 11.81 in × 6.14 in
- Operating Frequency Range : 2.400 to 2.4835 GHz
- Ingress Protection : IP65
- Common Alarm Relay : (3) 1.7 A, 30V DC or 250V AC
- Power Requirement : 110/220 VAC, 105 W, 18 to 32 VDC (+/-10%) Typical 24 VDC
- Application : Drilling Rigs and Petrochemical Plants|Industrial Safety, Exploration, Fracking, Plant Shutdown & Turn-Around|Steel Mills|Tank Farms, Shipyards and Maritime
- Approvals : CSA-C22.2 No. 61010-1-04|EMC/RFI (EN 50270:2015)|LVD (EN 61010-1:2010)|UL 61010-1 (3rd Edition) and 508
- Warranty : 12 Months or 18 Months
- Industry : Energy
- Outputs : 3 Common Alarm Outputs|4 Powered A/V Outputs for Alarms and Fault
Please sign in to access more documents.
Once signed in, you may be able to access additional documents for your account.
Name
Description
File Size
Date
Size
Name
Description
File Size
Date
Size
Product Number
Please sign in to view part numbers available for purchase based on your account Sign In
Part Number
Compare
Description
Leaf Category
Thumbnail
Add to list
029-3501-000-1
BATTERY PACK,LI BATTERY,RL3,MINICHG,C1D2
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
029-3501-000-1
BATTERY PACK,LI BATTERY,RL3,MINICHG,C1D2
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
029-3502-000
BATTERY PACK,ALKALINE,RAELINK III
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
029-3502-000
BATTERY PACK,ALKALINE,RAELINK III
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
D01-1016-00B
PCB ASSY,RM900A_M3,868MHZ,TPPLW
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
D01-1016-00B
PCB ASSY,RM900A_M3,868MHZ,TPPLW
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
F05-E030-024
FA324 24 VDC Alarm Bar for TPPLW
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
F05-E030-024
FA324 24 VDC Alarm Bar for TPPLW
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4BNNN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input with 4 x mA output, battery backup
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4BNNN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input with 4 x mA output, battery backup
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4BNRN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input, 4 x mA output with battery backup, MODBUS TCP+WEB monitoring
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4BNRN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input, 4 x mA output with battery backup, MODBUS TCP+WEB monitoring
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4BNTN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input, 4 x mA output with battery backup, MODBUS TCP
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4BNTN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input, 4 x mA output with battery backup, MODBUS TCP
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4BRNN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input, 4 x mA output with battery backup, MODBUS RTU
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4BRNN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input, 4 x mA output with battery backup, MODBUS RTU
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4NNNN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input with 4 x mA output
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4NNNN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input with 4 x mA output
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4NNRN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input, 4 x mA output, MODBUS TCP+WEB monitoring
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
TPPLBAWA2N4NNRN
TPPL Controller Basic, Wall Mount, AC115220 150W, 2 x mA input, 4 x mA output, MODBUS TCP+WEB monitoring
https://s7d1.scene7.com/is/image/Honeywell65/his-rae-tpplw-side-angled-newscreen-539x323
