Interruptores de fin de carrera
Serie HDLS
Carcasa de metal resistente. Conectable y no conectable. Sellado IP65/66/67. Orificios de montaje de 30 mm x 60 mm. Aprobaciones UL, CSA, CE, CCC
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Los interruptores final de carrera de uso intensivo Serie HDLS incluyen un diseño de cabezal de perno y zócalo para una retención más segura del cabezal al cuerpo, un tren de accionamiento completamente de metal para el funcionamiento continuo (incluso a altas temperaturas) y terminales de presión de autoelevación para optimizar el tiempo de cableado. Con su carcasa resistente, la Serie HDLS está sellada según NEMA 1, 3, 4, 4X, 6, 6P, 12, 13: IP65/66/67. Las versiones de lateral giratorio pueden modificarse para que funcionen en sentido horario o antihorario, mientras que los cabezales de operación pueden rotarse 90°. Se ofrecen opciones de sellado para bajas y altas temperaturas.
