Drucksensoren
26PC-Serie
Kompensiert. Niedriger Druck. mV Ausgang. Differenzial, Nass/Nass-Differenzial, Anzeige. DIP, SIP, SMT. Linearität und Hysterese: 0,5 % typ.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Druckbereiche
- 0,5.psi bis 250.psi (SIP, DIP)
- 1.psi bis 15.psi (SMT)
Die werkseingestellten Miniaturdrucksensoren der 26PC-Serie bieten verlässliche Relativdruckmessung in einem kompakten Gehäuse. Der Sensor weist eine bewährte Messtechnologie auf, die ein spezielles piezoresistives, mikrobearbeitetes Messelement verwendet. Dies ermöglicht die Austauschbarkeit von Teilen sowie eine hervorragende Leistung, Verlässlichkeit und Genauigkeit. Der nicht verstärkte und nicht kompensierte Wheatstone-Brückenkreis mit geringem Stromverbrauch ermöglicht einen stabilen mV-Ausgang im Messbereich zwischen 1,0.psi und 250.psi.
